4D9L

Fab structure of anti-HIV-1 gp120 V2 mAb 697


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.48 Å
  • R-Value Free: 0.238
  • R-Value Work: 0.176
  • R-Value Observed: 0.180

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Functional and immunochemical cross-reactivity of V2-specific monoclonal antibodies from HIV-1-infected individuals.

Gorny, M.K.Pan, R.Williams, C.Wang, X.H.Volsky, B.O'Neal, T.Spurrier, B.Sampson, J.M.Li, L.Seaman, M.S.Kong, X.P.Zolla-Pazner, S.

(2012) Virology 427: 198-207

  • DOI: https://doi.org/10.1016/j.virol.2012.02.003
  • Primary Citation of Related Structures:
    4D9L

  • PubMed Abstract:

    The recent analysis of the first successful RV144 vaccine trial revealed that a high titer of plasma anti-V2 antibodies (Abs) correlated with a decreased risk of HIV-1 infection in vaccine recipients. To understand the mechanism of immune correlates, we studied seven anti-V2 monoclonal Abs (mAbs) developed from HIV-1 infected individuals. The V2 mAbs target conserved epitopes, including the binding site for α4β7 integrin, and are broadly cross-reactive with various gp120 proteins. Preferential usage of the VH1-69 gene by V2 mAbs may depend on selection by the same antigenic structure. Six of seven V2 mAbs weakly neutralized four to eight of the 41 pseudoviruses tested and resistance to neutralization was correlated with longer V2 domains. The data suggest the presence of shared, conserved structural elements in the V2 loop, and these can be used in the design of vaccine immunogens inducing broadly reactive Abs with anti-viral activities.


  • Organizational Affiliation

    Department of Pathology, New York University School of Medicine, New York, NY 10016, USA. mirek.gorny@med.nyu.edu


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Light chain of Fab fragment of anti-HIV1 gp120 V2 mAb 697A [auth L],
C [auth M],
E [auth N],
G [auth O]
215Homo sapiensMutation(s): 0
UniProt
Find proteins for Q6GMX4 (Homo sapiens)
Explore Q6GMX4
Go to UniProtKB:  Q6GMX4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6GMX4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Heavy chain of Fab fragment of anti-HIV1 gp120 V2 mAb 697B [auth H],
D [auth I],
F [auth J],
H [auth K]
223Homo sapiensMutation(s): 0
UniProt
Find proteins for Q6GMX6 (Homo sapiens)
Explore Q6GMX6
Go to UniProtKB:  Q6GMX6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6GMX6
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.48 Å
  • R-Value Free: 0.238
  • R-Value Work: 0.176
  • R-Value Observed: 0.180
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 68.322α = 82.12
b = 82.46β = 70.41
c = 93.212γ = 86.27
Software Package:
Software NamePurpose
Blu-Icedata collection
MOLREPphasing
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2012-03-21
    Type: Initial release
  • Version 1.1: 2012-04-11
    Changes: Database references
  • Version 1.2: 2017-08-02
    Changes: Refinement description, Source and taxonomy
  • Version 1.3: 2023-09-13
    Changes: Data collection, Database references, Refinement description
