4D85

Crystal Structure of Human Beta Secretase in Complex with NVP-BVI151


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.65 Å
  • R-Value Free: 0.247
  • R-Value Work: 0.207
  • R-Value Observed: 0.209

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history


Literature

Discovery of cyclic sulfone hydroxyethylamines as potent and selective beta-site APP-cleaving enzyme 1 (BACE1) inhibitors: structure based design and in vivo reduction of amyloid beta-peptides

Rueeger, H.Lueoend, R.Rogel, O.Rondeau, J.M.Mobitz, H.Machauer, R.Jacobson, L.Staufenbiel, M.Desrayaud, S.Neumann, U.

(2012) J Med Chem 55: 3364-3386

  • DOI: 10.1021/jm300069y
  • Primary Citation of Related Structures:
    3VEU, 3VF3, 3VG1, 4D83, 4D85, 4D88, 4D89, 4D8C

  • PubMed Abstract:
  • Structure-based design of a series of cyclic hydroxyethylamine BACE1 inhibitors allowed the rational incorporation of prime- and nonprime-side fragments to a central core template without any amide functionality. The core scaffold selection and the structure-activity relationship development were supported by molecular modeling studies and by X-ray analysis of BACE1 complexes with various ligands to expedite the optimization of the series ...

    Structure-based design of a series of cyclic hydroxyethylamine BACE1 inhibitors allowed the rational incorporation of prime- and nonprime-side fragments to a central core template without any amide functionality. The core scaffold selection and the structure-activity relationship development were supported by molecular modeling studies and by X-ray analysis of BACE1 complexes with various ligands to expedite the optimization of the series. The direct extension from P1-aryl- and heteroaryl moieties into the S3 binding pocket allowed the enhancement of potency and selectivity over cathepsin D. Restraining the design and synthesis of compounds to a physicochemical property space consistent with central nervous system drugs led to inhibitors with improved blood-brain barrier permeability. Guided by structure-based optimization, we were able to obtain highly potent compounds such as 60p with enzymatic and cellular IC(50) values of 2 and 50 nM, respectively, and with >200-fold selectivity over cathepsin D. Pharmacodynamic studies in APP51/16 transgenic mice at oral doses of 180 μmol/kg demonstrated significant reduction of brain Aβ levels.


    Related Citations:
    • Structure-Based Design, synthesis and SAR of cyclic hydroxyethylamine (HEA) BACE-1 inhibitors
      Rueeger, H., Rondeau, J.M., McCarthy, C., Moebitz, H., Tintelnot-Blomley, M., Neumann, U., Desrayaud, S.
      (2011) Bioorg Med Chem Lett 21: 1942

    Organizational Affiliation

    Department of Global Discovery Chemistry, Institutes for BioMedical Research, Novartis Pharma AG, CH-4057 Basel, Switzerland. heinrich.rueeger@novartis.com



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Beta-secretase 1A408Homo sapiensMutation(s): 0
Gene Names: BACEBACE1KIAA1149
EC: 3.4.23.46
UniProt & NIH Common Fund Data Resources
Find proteins for P56817 (Homo sapiens)
Explore P56817
Go to UniProtKB:  P56817
PHAROS:  P56817
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
0GU (Subject of Investigation/LOI)
Query on 0GU

Download Ideal Coordinates CCD File
B [auth A](3R,4S,5S)-3-[(3-tert-butylbenzyl)amino]-5-[(4,4,7'-trifluoro-1',2'-dihydrospiro[cyclohexane-1,3'-indol]-5'-yl)methyl]tetrahydro-2H-thiopyran-4-ol 1,1-dioxide
C30 H39 F3 N2 O3 S
YSVPVGYQIWTLEZ-UDZXTKBFSA-N
 Ligand Interaction
IOD
Query on IOD

Download Ideal Coordinates CCD File
C [auth A]IODIDE ION
I
XMBWDFGMSWQBCA-UHFFFAOYSA-M
 Ligand Interaction
Binding Affinity Annotations
IDSourceBinding Affinity
0GU PDBBind:  4D85 IC50: 140 (nM) from 1 assay(s)
BindingDB:  4D85 IC50: min: 140, max: 3530 (nM) from 2 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.65 Å
  • R-Value Free: 0.247
  • R-Value Work: 0.207
  • R-Value Observed: 0.209
  • Space Group: P 61 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 102.656α = 90
b = 102.656β = 90
c = 170.902γ = 120
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
CNSrefinement
PDB_EXTRACTdata extraction
CNXphasing
CNXrefinement

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2012-11-21
    Type: Initial release
