3D structure of FliC from Burkholderia pseudomallei

Experimental Data Snapshot

  • Resolution: 1.30 Å
  • R-Value Free: 0.165
  • R-Value Work: 0.136
  • R-Value Observed: 0.138

wwPDB Validation   3D Report Full Report

This is version 1.2 of the entry. See complete history


Sequence- and Structure-Based Immunoreactive Epitope Discovery for Burkholderia Pseudomallei Flagellin.

Nithichanon, A.Rinchai, D.Gori, A.Lassaux, P.Peri, C.Conchillio-Sole, O.Ferrer-Navarro, M.Gourlay, L.J.Nardini, M.Vila, J.Daura, X.Colombo, G.Bolognesi, M.Lertmemonkolchai, G.

(2015) PLoS Negl Trop Dis 9: 03917

  • DOI: https://doi.org/10.1371/journal.pntd.0003917
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    Burkholderia pseudomallei is a Gram-negative bacterium responsible for melioidosis, a serious and often fatal infectious disease that is poorly controlled by existing treatments. Due to its inherent resistance to the major antibiotic classes and its facultative intracellular pathogenicity, an effective vaccine would be extremely desirable, along with appropriate prevention and therapeutic management. One of the main subunit vaccine candidates is flagellin of Burkholderia pseudomallei (FliCBp). Here, we present the high resolution crystal structure of FliCBp and report the synthesis and characterization of three peptides predicted to be both B and T cell FliCBp epitopes, by both structure-based in silico methods, and sequence-based epitope prediction tools. All three epitopes were shown to be immunoreactive against human IgG antibodies and to elicit cytokine production from human peripheral blood mononuclear cells. Furthermore, two of the peptides (F51-69 and F270-288) were found to be dominant immunoreactive epitopes, and their antibodies enhanced the bactericidal activities of purified human neutrophils. The epitopes derived from this study may represent potential melioidosis vaccine components.

  • Organizational Affiliation

    The Centre for Research and Development of Medical Diagnostic Laboratories, Faculty of Associated Medical Sciences, Khon Kaen University, Khon Kaen, Thailand.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
FLAGELLIN258Burkholderia pseudomallei K96243Mutation(s): 0
Find proteins for P70944 (Burkholderia pseudomallei)
Explore P70944
Go to UniProtKB:  P70944
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP70944
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 1.30 Å
  • R-Value Free: 0.165
  • R-Value Work: 0.136
  • R-Value Observed: 0.138
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 23.47α = 90
b = 72.78β = 90
c = 125.57γ = 90
Software Package:
Software NamePurpose
MOSFLMdata reduction
SCALAdata scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-12-10
    Type: Initial release
  • Version 1.1: 2016-03-02
    Changes: Database references
  • Version 1.2: 2023-12-20
    Changes: Data collection, Database references, Other, Refinement description
