4BZ0

Structural characterization using Sulfur-SAD of the cytoplasmic domain of Burkholderia pseudomallei PilO2Bp, an actin-like protein component of a Type IVb R64-derivative pilus machinery.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.76 Å
  • R-Value Free: 0.250
  • R-Value Work: 0.191

wwPDB Validation 3D Report Full Report


This is version 1.0 of the entry. See complete history

Literature

Redefining the Pf06864 Pfam Family Based on Burkholderia Pseudomallei Pilo2BP S-Sad Crystal Structure.

Lassaux, P.Conchillo-Sole, O.Manjasetty, B.A.Yero, D.Perletti, L.Belrhali, H.Daura, X.Gourlay, L.J.Bolognesi, M.

(2014) Plos One 9: 94981

  • DOI: 10.1371/journal.pone.0094981
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Type IV pili are surface-exposed filaments and bacterial virulence factors, represented by the Tfpa and Tfpb types, which assemble via specific machineries. The Tfpb group is further divided into seven variants, linked to heterogeneity in the assembl ...

    Type IV pili are surface-exposed filaments and bacterial virulence factors, represented by the Tfpa and Tfpb types, which assemble via specific machineries. The Tfpb group is further divided into seven variants, linked to heterogeneity in the assembly machineries. Here we focus on PilO2(Bp), a protein component of the Tfpb R64 thin pilus variant assembly machinery from the pathogen Burkholderia pseudomallei. PilO2(Bp) belongs to the PF06864 Pfam family, for which an improved definition is presented based on newly derived Hidden Markov Model (HMM) profiles. The 3D structure of the N-terminal domain of PilO2(Bp) (N-PilO2(Bp)), here reported, is the first structural representative of the PF06864 family. N-PilO2(Bp) presents an actin-like ATPase fold that is shown to be present in BfpC, a different variant assembly protein; the new HMM profiles classify BfpC as a PF06864 member. Our results provide structural insight into the PF06864 family and on the Type IV pili assembly machinery.


    Organizational Affiliation

    Department of Biosciences, University of Milan, Milan, Italy.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
PUTATIVE TYPE IV PILUS BIOSYNTHESIS PROTEIN
A
192Burkholderia pseudomallei (strain K96243)Mutation(s): 0
Gene Names: pilO
Find proteins for Q63JW5 (Burkholderia pseudomallei (strain K96243))
Go to UniProtKB:  Q63JW5
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
K
Query on K

Download SDF File
Download CCD File
A
POTASSIUM ION
K
NPYPAHLBTDXSSS-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.76 Å
  • R-Value Free: 0.250
  • R-Value Work: 0.191
  • Space Group: P 41 21 2
Unit Cell:
Length (Å)Angle (°)
a = 52.740α = 90.00
b = 52.740β = 90.00
c = 127.020γ = 90.00
Software Package:
Software NamePurpose
MOSFLMdata reduction
SCALAdata scaling
REFMACrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2014-04-23
    Type: Initial release
