4BTQ

Coordinates of the bacteriophage phi6 capsid subunits fitted into the cryoEM map EMD-1206


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 7.50 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Subunit Folds and Maturation Pathway of a Dsrna Virus Capsid.

Nemecek, D.Boura, E.Wu, W.Cheng, N.Plevka, P.Qiao, J.Mindich, L.Heymann, J.B.Hurley, J.H.Steven, A.C.

(2013) Structure 21: 1374

  • DOI: 10.1016/j.str.2013.06.007
  • Primary Citation of Related Structures:
    4BTQ, 4BTG, 4K7H

  • PubMed Abstract:
  • The cystovirus ϕ6 shares several distinct features with other double-stranded RNA (dsRNA) viruses, including the human pathogen, rotavirus: segmented genomes, nonequivalent packing of 120 subunits in its icosahedral capsid, and capsids as compartments for transcription and replication ...

    The cystovirus ϕ6 shares several distinct features with other double-stranded RNA (dsRNA) viruses, including the human pathogen, rotavirus: segmented genomes, nonequivalent packing of 120 subunits in its icosahedral capsid, and capsids as compartments for transcription and replication. ϕ6 assembles as a dodecahedral procapsid that undergoes major conformational changes as it matures into the spherical capsid. We determined the crystal structure of the capsid protein, P1, revealing a flattened trapezoid subunit with an α-helical fold. We also solved the procapsid with cryo-electron microscopy to comparable resolution. Fitting the crystal structure into the procapsid disclosed substantial conformational differences between the two P1 conformers. Maturation via two intermediate states involves remodeling on a similar scale, besides huge rigid-body rotations. The capsid structure and its stepwise maturation that is coupled to sequential packaging of three RNA segments sets the cystoviruses apart from other dsRNA viruses as a dynamic molecular machine.


    Organizational Affiliation

    National Institute of Arthritis and Musculoskeletal and Skin Diseases, National Institutes of Health, 50 South Drive, Bethesda, MD 20892, USA.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
MAJOR INNER PROTEIN P1A, B761Pseudomonas virus phi6Mutation(s): 0
Gene Names: P1
UniProt
Find proteins for P11126 (Pseudomonas phage phi6)
Explore P11126
Go to UniProtKB:  P11126
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 7.50 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2013-12-11
    Type: Initial release
  • Version 1.1: 2017-08-30
    Changes: Data collection
  • Version 1.2: 2018-10-03
    Changes: Data collection
