4BN1

Crystal structure of V174M mutant of Aurora-A kinase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.499 Å
  • R-Value Free: 0.244
  • R-Value Work: 0.192

wwPDB Validation 3D Report Full Report


This is version 1.0 of the entry. See complete history

Literature

Insights Into Aurora-A Kinase Activation Using Unnatural Amino Acids Incorporated by Chemical Modification.

Rowan, F.C.Richards, M.Bibby, R.A.Thompson, A.Bayliss, R.Blagg, J.

(2013) Acs Chem.Biol. 8: 2184

  • DOI: 10.1021/cb400425t

  • PubMed Abstract:
  • Most protein kinases are regulated through activation loop phosphorylation, but the contributions of individual sites are largely unresolved due to insufficient control over sample phosphorylation. Aurora-A is a mitotic Ser/Thr protein kinase that ha ...

    Most protein kinases are regulated through activation loop phosphorylation, but the contributions of individual sites are largely unresolved due to insufficient control over sample phosphorylation. Aurora-A is a mitotic Ser/Thr protein kinase that has two regulatory phosphorylation sites on its activation loop, T287 and T288. While phosphorylation of T288 is known to activate the kinase, the function of T287 phosphorylation is unclear. We applied site-directed mutagenesis and selective chemical modification to specifically introduce bioisosteres for phospho-threonine and other unnatural amino acids at these positions. Modified Aurora-A proteins were characterized using a biochemical assay measuring substrate phosphorylation. Replacement of T288 with glutamate and aspartate weakly stimulated activity. Phospho-cysteine, installed by chemical synthesis from a corresponding cysteine residue introduced at position 288, showed catalytic activity approaching that of the comparable phospho-serine protein. Unnatural amino acid residues, with longer side chains, inserted at position 288 were autophosphorylated and supported substrate phosphorylation. Aurora-A activity is enhanced by phosphorylation at position 287 alone but is suppressed when position 288 is also phosphorylated. This is rationalized by competition between phosphorylated T287 and T288 for a binding site composed of arginines, based on a structure of Aurora-A in which phospho-T287 occupies this site. This is, to our knowledge, the first example of a Ser/Thr kinase whose activity is controlled by the phosphorylation state of adjacent residues in its activation loop. Overall we demonstrate an approach that combines mutagenesis and selective chemical modification of selected cysteine residues to investigate otherwise impenetrable aspects of kinase regulation.


    Organizational Affiliation

    Cancer Research UK Cancer Therapeutics Unit, Division of Cancer Therapeutics, The Institute of Cancer Research , 15 Cotswold Road, Sutton, Surrey, SM2 5NG, U.K.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
AURORA KINASE A
A
285Homo sapiensMutation(s): 1
Gene Names: AURKA (AIK, AIRK1, ARK1, AURA, AYK1, BTAK, IAK1, STK15, STK6)
EC: 2.7.11.1
Find proteins for O14965 (Homo sapiens)
Go to Gene View: AURKA
Go to UniProtKB:  O14965
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ADP
Query on ADP

Download SDF File
Download CCD File
A
ADENOSINE-5'-DIPHOSPHATE
C10 H15 N5 O10 P2
XTWYTFMLZFPYCI-KQYNXXCUSA-N
 Ligand Interaction
CA
Query on CA

Download SDF File
Download CCD File
A
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
TPO
Query on TPO
A
L-PEPTIDE LINKINGC4 H10 N O6 PTHR
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.499 Å
  • R-Value Free: 0.244
  • R-Value Work: 0.192
  • Space Group: P 61 2 2
Unit Cell:
Length (Å)Angle (°)
a = 81.615α = 90.00
b = 81.615β = 90.00
c = 175.385γ = 120.00
Software Package:
Software NamePurpose
PHENIXrefinement
SCALAdata scaling
MOSFLMdata reduction
PHASERphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2014-03-26
    Type: Initial release
