4B54

The Structure of the inactive mutant G153R of LptC from E. coli


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.8 Å
  • R-Value Free: 0.266
  • R-Value Work: 0.240

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

The Escherichia Coli Lpt Transenvelope Protein Complex for Lipopolysaccharide Export is Assembled Via Conserved Structurally Homologous Domains.

Villa, R.Martorana, A.M.Okuda, S.Gourlay, L.J.Nardini, M.Sperandeo, P.Deho, G.Bolognesi, M.Kahne, D.Polissi, A.

(2013) J.Bacteriol. 195: 1100

  • DOI: 10.1128/JB.02057-12

  • PubMed Abstract:
  • Lipopolysaccharide is a major glycolipid component in the outer leaflet of the outer membrane (OM), a peculiar permeability barrier of Gram-negative bacteria that prevents many toxic compounds from entering the cell. Lipopolysaccharide transport (Lpt ...

    Lipopolysaccharide is a major glycolipid component in the outer leaflet of the outer membrane (OM), a peculiar permeability barrier of Gram-negative bacteria that prevents many toxic compounds from entering the cell. Lipopolysaccharide transport (Lpt) across the periplasmic space and its assembly at the Escherichia coli cell surface are carried out by a transenvelope complex of seven essential Lpt proteins spanning the inner membrane (LptBCFG), the periplasm (LptA), and the OM (LptDE), which appears to operate as a unique machinery. LptC is an essential inner membrane-anchored protein with a large periplasm-protruding domain. LptC binds the inner membrane LptBFG ABC transporter and interacts with the periplasmic protein LptA. However, its role in lipopolysaccharide transport is unclear. Here we show that LptC lacking the transmembrane region is viable and can bind the LptBFG inner membrane complex; thus, the essential LptC functions are located in the periplasmic domain. In addition, we characterize two previously described inactive single mutations at two conserved glycines (G56V and G153R, respectively) of the LptC periplasmic domain, showing that neither mutant is able to assemble the transenvelope machinery. However, while LptCG56V failed to copurify any Lpt component, LptCG153R was able to interact with the inner membrane protein complex LptBFG. Overall, our data further support the model whereby the bridge connecting the inner and outer membranes would be based on the conserved structurally homologous jellyroll domain shared by five out of the seven Lpt components.


    Organizational Affiliation

    Dipartimento di Biotecnologie e Bioscienze, Università di Milano-Bicocca, Milan, Italy.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
LIPOPOLYSACCHARIDE EXPORT SYSTEM PROTEIN LPTC
A, B
176Escherichia coli (strain K12)Gene Names: lptC (yrbK)
Find proteins for P0ADV9 (Escherichia coli (strain K12))
Go to UniProtKB:  P0ADV9
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ACT
Query on ACT

Download SDF File
Download CCD File
A
ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.8 Å
  • R-Value Free: 0.266
  • R-Value Work: 0.240
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 40.940α = 90.00
b = 98.280β = 90.00
c = 123.560γ = 90.00
Software Package:
Software NamePurpose
XDSdata reduction
REFMACrefinement
MOLREPphasing
SCALAdata scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2013-01-16
    Type: Initial release
  • Version 1.1: 2013-02-20
    Type: Database references
