4A1R | pdb_00004a1r

The Structure of Serratia marcescens Lip, a membrane bound component of the Type VI Secretion System.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.92 Å
  • R-Value Free:
    0.292 (Depositor), 0.288 (DCC)
  • R-Value Work:
    0.220 (Depositor), 0.219 (DCC)
  • R-Value Observed:
    0.224 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 4A1R

This is version 1.4 of the entry. See complete history

Literature

The Structure of Serratia Marcescens Lip, a Membrane-Bound Component of the Type Vi Secretion System

Rao, V.A.Shepherd, S.M.English, G.Coulthurst, S.J.Hunter, W.N.

(2011) Acta Crystallogr Sect F Struct Biol Cryst Commun 67: 1065

  • DOI: https://doi.org/10.1107/S0907444911046300
  • Primary Citation Related Structures:
    4A1R

  • PubMed Abstract:

    Lip is a membrane-bound lipoprotein and a core component of the type VI secretion system found in Gram-negative bacteria. The structure of a Lip construct (residues 29-176) from Serratia marcescens (SmLip) has been determined at 1.92 Å resolution. Experimental phases were derived using a single-wavelength anomalous dispersion approach on a sample cocrystallized with iodide. The membrane localization of the native protein was confirmed. The structure is that of the globular domain lacking only the lipoprotein signal peptide and the lipidated N-terminus of the mature protein. The protein fold is dominated by an eight-stranded β-sandwich and identifies SmLip as a new member of the transthyretin family of proteins. Transthyretin and the only other member of the family fold, 5-hydroxyisourate hydrolase, form homotetramers important for their function. The asymmetric unit of SmLip is a tetramer with 222 symmetry, but the assembly is distinct from that previously noted for the transthyretin protein family. However, structural comparisons and bacterial two-hybrid data suggest that the SmLip tetramer is not relevant to its role as a core component of the type VI secretion system, but rather reflects a propensity for SmLip to participate in protein-protein interactions. A relatively low level of sequence conservation amongst Lip homologues is noted and is restricted to parts of the structure that might be involved in interactions with physiological partners.


  • Organizational Affiliation
    • College of Life Sciences, University of Dundee, Dundee DD1 5EH, Scotland.

Macromolecule Content

  • Total Structure Weight: 65.45 kDa
  • Atom Count: 4,787
  • Modeled Residue Count: 558
  • Deposited Residue Count: 596
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
LIP
A, B, C, D
149Serratia marcescensMutation(s): 0
UniProt
Find proteins for G5EA77 (Serratia marcescens)
Explore G5EA77
Go to UniProtKB:  G5EA77
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG5EA77
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.92 Å
  • R-Value Free:  0.292 (Depositor), 0.288 (DCC)
  • R-Value Work:  0.220 (Depositor), 0.219 (DCC)
  • R-Value Observed: 0.224 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 139.73α = 90
b = 77.75β = 98.31
c = 54.49γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
SCALAdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2011-10-05
    Type: Initial release
  • Version 1.1: 2011-11-30
    Changes: Database references
  • Version 1.2: 2012-02-29
    Changes: Other
  • Version 1.3: 2013-03-20
    Changes: Derived calculations
  • Version 1.4: 2024-05-01
    Changes: Data collection, Database references, Derived calculations, Other, Refinement description
