441D

HIGH RESOLUTION A-DNA CRYSTAL STRYCTURES OF D(AGGGGCCCCT): AN A-DNA MODEL OF POLY(DG).POLY(DC)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.5 Å
  • R-Value Free: 0.315
  • R-Value Work: 0.236

wwPDB Validation 3D Report Full Report


This is version 1.4 of the entry. See complete history

Literature

High-resolution A-DNA crystal structures of d(AGGGGCCCCT). An A-DNA model of poly(dG) x poly(dC).

Gao, Y.G.Robinson, H.Wang, A.H.

(1999) Eur.J.Biochem. 261: 413-420

  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • A-DNA conformation is favored by guanine-rich sequences, such as (dG)n x (dC)n, or under low-humidity conditions. Earlier A-DNA crystal structures revealed some conformational variations which may be the result of sequence-dependent effects and/or cr ...

    A-DNA conformation is favored by guanine-rich sequences, such as (dG)n x (dC)n, or under low-humidity conditions. Earlier A-DNA crystal structures revealed some conformational variations which may be the result of sequence-dependent effects and/or crystal packing forces. Here we report the high-resolution crystal structure of d(AGGGGCCCCT) in two crystal forms (either in the P212121 or the P6122 space group) to gain insights into the conformation and dynamics of the (dG)n x (dC)n sequence. The P212121 form has been analyzed using data to 1.1 A resolution by the anisotropic temperature factor refinement procedure of the SHELX97 program. Such analysis affords us with the detailed geometric, conformational and motional property of an A-DNA structure. The backbone torsional angles fall in a narrow range, except for the alpha/gamma angles which have two distinct combinations (gauche-/gauche+ or trans/trans). An A-DNA model of poly(dG) x poly(dC) has been constructed using the conformational parameters derived from the crystal structure of the P212121 form. In the crystal structure of the P6122 space group, the central eight base pairs of the decamer adopt A-DNA conformation with the two terminal nucleotides flipped out to form base pairs with the neighboring nucleotides. Comparison of the A-DNA structure of the same sequence from two different crystal forms, reinforced the conclusion that molecules crystallized in the same space group have a more similar conformation, whereas the same molecule crystallized in different space groups has different (local) conformations.


    Organizational Affiliation

    Department of Cell & Structural Biology, University of Illinois at Urbana-Champaign, Urbana, IL 61801, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsLengthOrganism
DNA (5'-D(*AP*GP*GP*GP*GP*CP*CP*CP*CP*T)-3')A10synthetic construct
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.5 Å
  • R-Value Free: 0.315
  • R-Value Work: 0.236
  • Space Group: P 61 2 2
Unit Cell:
Length (Å)Angle (°)
a = 32.765α = 90.00
b = 32.765β = 90.00
c = 77.754γ = 120.00
Software Package:
Software NamePurpose
X-PLORrefinement
X-PLORphasing
BIOTEXdata reduction
X-PLORmodel building
BIOTEXdata scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 1999-01-15
    Type: Initial release
  • Version 1.1: 2008-05-22
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
  • Version 1.3: 2014-11-19
    Type: Other
  • Version 1.4: 2017-05-03
    Type: Source and taxonomy, Structure summary
