420D

CRYSTAL STRUCTURE OF A 16-MER RNA DUPLEX WITH NON-ADJACENT A(ANTI).G(SYN) MISMATCHES


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free: 0.296
  • R-Value Work: 0.197
  • R-Value Observed: 0.197

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Crystal structure of an RNA 16-mer duplex R(GCAGAGUUAAAUCUGC)2 with nonadjacent G(syn).A+(anti) mispairs.

Pan, B.Mitra, S.N.Sundaralingam, M.

(1999) Biochemistry 38: 2826-2831

  • DOI: 10.1021/bi982122y
  • Primary Citation of Related Structures:
    420D

  • PubMed Abstract:
  • G.A mispairs are one of the most common noncanonical structural motifs of RNA. The 1.9 A resolution crystal structure of the RNA 16-mer r(GCAGAGUUAAAUCUGC)2 has been determined with two isolated or nonadjacent G.A mispairs. The molecule crystallizes with one duplex in the asymmetric unit in space group R3 and unit cell dimensions a = b = c = 49 ...

    G.A mispairs are one of the most common noncanonical structural motifs of RNA. The 1.9 A resolution crystal structure of the RNA 16-mer r(GCAGAGUUAAAUCUGC)2 has been determined with two isolated or nonadjacent G.A mispairs. The molecule crystallizes with one duplex in the asymmetric unit in space group R3 and unit cell dimensions a = b = c = 49.24 A and alpha = beta = gamma = 51.2 degrees. It is the longest known oligonucleotide duplex at this resolution and isomorphous to the 16-mer duplex with the C.A+ mispairs [Pan, et al., (1998) J. Mol. Biol. 283, 977-984]. The C.A+ mispair behaves like a wobble pair while the G.A+ does not. The G.A mispairs are protonated at N1 of the adenines as in the C.A+ mispairs, and two hydrogen bonds in the G(syn).A+(anti) conformation are formed. The syn guanine is stabilized by an intranucleotide hydrogen bond between the 2-amino and the 5'-phosphate groups. The G(syn).A+(anti) conformation can provide a different surface for recognition in the grooves compared to other G.A hydrogen bonding schemes. The major groove is widened between the two mispairs allowing access to ligands. One of the 3-fold axes is occupied by a sodium ion and a water molecule, while a second is occupied by another water molecule.


    Organizational Affiliation

    Biological Macromolecular Structure Center, Department of Chemistry, The Ohio State University, Columbus 43210-1002, USA.



Macromolecules

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 1
MoleculeChainsLengthOrganismImage
RNA (5'-R(*GP*CP*AP*GP*AP*GP*UP*UP*AP*AP*AP*UP*CP*UP*GP*C)-3')A, B 16N/A
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
NA
Query on NA

Download Ideal Coordinates CCD File
C [auth A]SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free: 0.296
  • R-Value Work: 0.197
  • R-Value Observed: 0.197
  • Space Group: H 3
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 42.53α = 90
b = 42.53β = 90
c = 128.06γ = 120
Software Package:
Software NamePurpose
X-PLORrefinement
R-AXISdata reduction
MSCdata scaling

Structure Validation

View Full Validation Report




Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1999-01-13
    Type: Initial release
  • Version 1.1: 2008-05-22
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
