Crystal structures of polyamine receptors SpuD and SpuE from Pseudomonas aeruginosa

Experimental Data Snapshot

  • Resolution: 2.00 Å
  • R-Value Free: 0.244
  • R-Value Work: 0.212
  • R-Value Observed: 0.213

wwPDB Validation   3D Report Full Report

This is version 1.0 of the entry. See complete history


Structural Basis of Substrate Binding Specificity Revealed by the Crystal Structures of Polyamine Receptors SpuD and SpuE from Pseudomonas aeruginosa

Wu, D.H.Lim, S.C.Dong, Y.H.Wu, J.E.Tao, F.Zhou, L.Zhang, L.H.Song, H.W.

(2012) J Mol Biol 416: 697-712

  • DOI: https://doi.org/10.1016/j.jmb.2012.01.010
  • Primary Citation of Related Structures:
    3TTK, 3TTL, 3TTM, 3TTN

  • PubMed Abstract:

    The type III secretion system (T3SS) of Pseudomonas aeruginosa is a key virulence determinant whose expression is induced by polyamine signals from mammalian host. SpuD and SpuE were postulated to be spermidine-preferential binding proteins, which regulate the polyamine content in this bacterial pathogen. In this study, we found that SpuD is a putrescine-preferential binding protein, while SpuE binds to spermidine exclusively. We have determined the crystal structures of SpuD in free form and in complex with putrescine and SpuE in free form and in complex with spermidine. Upon ligand binding, SpuD and SpuE undergo an "open-to-closed" conformational switch with the resultant closed ligand-bound forms, SpuD-putrescine and SpuE-spermidine, similar to their Escherichia coli counterparts PotF-putrescine and PotD-spermidine, respectively. Structural comparison suggested that two aromatic residues, Trp271 of SpuE and Phe273 of SpuD in segment II region, are the key structural determinants for putrescine/spermidine recognition specificity. Mutagenesis combined with isothermal titration calorimetry showed that substitution of Trp271 by Phe enabled SpuE to gain substantial binding affinity for putrescine, while replacement of Phe273 by Trp reduced the binding affinity of SpuD toward putrescine by 250-fold. Altogether, these results revealed the molecular mechanism governing polyamine recognition specificity by SpuD and SpuE and provide the basis for further structural and functional studies of polyamine signal importation system in P. aeruginosa.

  • Organizational Affiliation

    Institute of Molecular and Cell Biology, 61 Biopolis Drive, Proteos, Singapore 138673.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Polyamine transport protein
A, B
340Pseudomonas aeruginosaMutation(s): 0
Gene Names: spuE
Find proteins for Q9I6J0 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1))
Explore Q9I6J0
Go to UniProtKB:  Q9I6J0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9I6J0
Sequence Annotations
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
Query on MSE
A, B
Binding Affinity Annotations
IDSourceBinding Affinity
SPD Binding MOAD:  3TTN Kd: 14.3 (nM) from 1 assay(s)
PDBBind:  3TTN Kd: 14.3 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Resolution: 2.00 Å
  • R-Value Free: 0.244
  • R-Value Work: 0.212
  • R-Value Observed: 0.213
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 44.329α = 91.5
b = 44.367β = 95.24
c = 81.553γ = 95.23
Software Package:
Software NamePurpose
MOSFLMdata reduction
XDSdata reduction
SCALAdata scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2012-03-28
    Type: Initial release
