Biological Assembly 1

 3D View: Structure | 1D-3D View | Electron Density | Validation Report

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 2-mer - A1B1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 61.58 kDa
• Atom Count: 3758
• Modelled Residue Count: 464
• Deposited Residue Count: 538
• Unique protein chains: 2

3TG1

Crystal structure of p38alpha in complex with a MAPK docking partner

• PDB DOI: 10.2210/pdb3TG1/pdb

• Classification: TRANSFERASE/HYDROLASE
• Organism(s): Mus musculus, Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2011-08-17 Released: 2012-03-14
• Deposition Author(s): Zhang, Y.Y., Wu, J.W., Wang, Z.X.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.71 Å
• R-Value Free: 0.260
• R-Value Work: 0.216
• R-Value Observed: 0.218

Literature

A Distinct Interaction Mode Revealed by the Crystal Structure of the Kinase p38alpha with the MAPK Binding Domain of the Phosphatase MKP5.

Zhang, Y.Y., Wu, J.W., Wang, Z.X.

(2011) Sci Signal 4: ra88-ra88

• PubMed: 22375048
• DOI: 10.1126/scisignal.2002241
• Primary Citation of Related Structures:
  3TG1, 3TG3


• PubMed Abstract:


The mitogen-activated protein kinase (MAPK) cascades play a pivotal role in a myriad of cellular functions. The specificity and efficiency of MAPK signaling are controlled by docking interactions between MAPKs and their cognate proteins. Many MAPK-interacting partners, including substrates, MAPK kinases, phosphatases, and scaffolding proteins, have linear sequence motifs that mediate the interaction with the common docking site on MAPKs. We report the crystal structure of p38α in complex with the MAPK binding domain (KBD) from MAPK phosphatase 5 (MKP5) at 2.7 Å resolution. In contrast to the well-known docking mode, the KBD binds p38α in a bipartite manner, in which two distinct helical regions of KBD engage the p38α docking site, which is situated on the back of the p38α active site. We also determined the crystal structure of the KBD of MKP7, which closely resembles the MKP5 KBD, suggesting that the mechanism of molecular recognition by the KBD of MKP5 is conserved in the cytoplasmic p38- and c-Jun N-terminal kinase-specific MKP subgroup. This previously unknown binding mode provides new insights into how MAPKs interact with their binding partners to achieve functional specificity.

---

Organizational Affiliation:

Ministry of Education Key Laboratory for Protein Science, School of Life Sciences, Tsinghua University, Beijing 100084, PR China.

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitogen-activated protein kinase 14	A	380	Mus musculus	Mutation(s): 0  Gene Names: Mapk14, Crk1, Csbp1, Csbp2 EC: 2.7.11.24
UniProt
Find proteins for P47811 (Mus musculus) Explore P47811  Go to UniProtKB:  P47811

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Dual specificity protein phosphatase 10	B	158	Homo sapiens	Mutation(s): 0  Gene Names: DUSP10, MKP5 EC: 3.1.3.16 (PDB Primary Data), 3.1.3.48 (PDB Primary Data)
UniProt & NIH Common Fund Data Resources
Find proteins for Q9Y6W6 (Homo sapiens) Explore Q9Y6W6  Go to UniProtKB:  Q9Y6W6
PHAROS:  Q9Y6W6 GTEx:  ENSG00000143507

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.71 Å
• R-Value Free: 0.260
• R-Value Work: 0.216
• R-Value Observed: 0.218
• Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 72.428	α = 90
b = 72.428	β = 90
c = 226.143	γ = 90

Software Package:

Software Name	Purpose
MAR345dtb	data collection
PHASER	phasing
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

Entry History

Deposition Data

• Deposited Date: 2011-08-17
• Released Date: 2012-03-14
Deposition Author(s): Zhang, Y.Y., Wu, J.W., Wang, Z.X.

Revision History

• Version 1.0: 2012-03-14
  Type: Initial release
