3T71

Crystal Structure of Steccherinum ochraceum Laccase obtained by multi-crystals composite data collection technique (90% dose)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.15 Å
  • R-Value Free: 0.246
  • R-Value Work: 0.176
  • R-Value Observed: 0.180

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 2.1 of the entry. See complete history


Literature

Reaction intermediates and redox state changes in a blue laccase from Steccherinum ochraceum observed by crystallographic high/low X-ray dose experiments.

Ferraroni, M.Matera, I.Chernykh, A.Kolomytseva, M.Golovleva, L.A.Scozzafava, A.Briganti, F.

(2012) J Inorg Biochem 111: 203-209

  • DOI: https://doi.org/10.1016/j.jinorgbio.2012.01.011
  • Primary Citation of Related Structures:
    3T6V, 3T6W, 3T6X, 3T6Z, 3T71

  • PubMed Abstract:

    The crystal structure of a blue laccase from Steccherinum ochraceum has been solved at 2.0Å of resolution using a classic data acquisition from a single crystal. The overall structural features are typical of this class of enzymes, however, distances inside the trinuclear copper cluster are indicative of a reduction of the metal centers induced by free electrons produced during the X-ray data collection. UV-visible spectra collected during the X-ray exposure support the progressive reduction of the metal centers. In order to better detect the reduction progression steps in the trinuclear copper site, a multicrystal data collection strategy based on a systematic spread of the X-ray dose over many crystals has been employed. This approach is based on collecting multicrystal data sets, then combining the slices of the individual data sets experiencing the same radiation dose to obtain composite complete data sets at progressively higher doses. Applying this technique, we have been able to capture sequential frames of the enzyme during the metal centers and molecular oxygen reduction mechanism obtaining a three-dimensional movie of the X-ray-driven catalytic conversion of the molecular oxygen in the active site of laccase: first, the copper ions reduction, then the molecular oxygen binding and its reductive splitting, thus allowing to reconstruct the entire catalytic cycle for multicopper oxidases.


  • Organizational Affiliation

    Dipartimento di Chimica, Università di Firenze, Via della Lastruccia 3, Sesto Fiorentino, Florence, Italy.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Laccase
A, B, C
495Steccherinum ochraceumMutation(s): 0
UniProt
Find proteins for I1SB14 (Steccherinum ochraceum)
Explore I1SB14
Go to UniProtKB:  I1SB14
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupI1SB14
Glycosylation
Glycosylation Sites: 2
Sequence Annotations
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 2
MoleculeChains Length2D Diagram Glycosylation3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
D, E, F, G, H
2N-Glycosylation
Glycosylation Resources
GlyTouCan:  G42666HT
GlyCosmos:  G42666HT
GlyGen:  G42666HT
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
NAG
Query on NAG

Download Ideal Coordinates CCD File
JA [auth C]2-acetamido-2-deoxy-beta-D-glucopyranose
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
SO4
Query on SO4

Download Ideal Coordinates CCD File
GA [auth C]
HA [auth C]
M [auth A]
N [auth A]
O [auth A]
GA [auth C],
HA [auth C],
M [auth A],
N [auth A],
O [auth A],
W [auth B],
X [auth B]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
GOL
Query on GOL

Download Ideal Coordinates CCD File
AA [auth B]
BA [auth B]
IA [auth C]
P [auth A]
Q [auth A]
AA [auth B],
BA [auth B],
IA [auth C],
P [auth A],
Q [auth A],
R [auth A],
Y [auth B],
Z [auth B]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
CU
Query on CU

Download Ideal Coordinates CCD File
CA [auth C]
DA [auth C]
EA [auth C]
FA [auth C]
I [auth A]
CA [auth C],
DA [auth C],
EA [auth C],
FA [auth C],
I [auth A],
J [auth A],
K [auth A],
L [auth A],
S [auth B],
T [auth B],
U [auth B],
V [auth B]
COPPER (II) ION
Cu
JPVYNHNXODAKFH-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.15 Å
  • R-Value Free: 0.246
  • R-Value Work: 0.176
  • R-Value Observed: 0.180
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 73.51α = 90
b = 140.04β = 90
c = 172.98γ = 90
Software Package:
Software NamePurpose
XSCALEdata scaling
REFMACrefinement
PDB_EXTRACTdata extraction
MAR345dtbdata collection
XDSdata reduction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2012-04-18
    Type: Initial release
  • Version 1.1: 2012-08-29
    Changes: Database references
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Advisory, Atomic model, Data collection, Derived calculations, Non-polymer description, Structure summary
  • Version 2.1: 2023-09-13
    Changes: Data collection, Database references, Derived calculations, Refinement description, Structure summary
