3SLP

Crystal Structure of Lambda Exonuclease in Complex with a 12 BP Symmetric DNA Duplex


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.3 Å
  • R-Value Free: 0.281
  • R-Value Work: 0.211

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Crystal structures of {lambda} exonuclease in complex with DNA suggest an electrostatic ratchet mechanism for processivity.

Zhang, J.McCabe, K.A.Bell, C.E.

(2011) Proc.Natl.Acad.Sci.USA 108: 11872-11877

  • DOI: 10.1073/pnas.1103467108
  • Primary Citation of Related Structures:  3SM4

  • PubMed Abstract:
  • The λ exonuclease is an ATP-independent enzyme that binds to dsDNA ends and processively digests the 5'-ended strand to form 5' mononucleotides and a long 3' overhang. The crystal structure of λ exonuclease revealed a toroidal homotrimer with a centr ...

    The λ exonuclease is an ATP-independent enzyme that binds to dsDNA ends and processively digests the 5'-ended strand to form 5' mononucleotides and a long 3' overhang. The crystal structure of λ exonuclease revealed a toroidal homotrimer with a central funnel-shaped channel for tracking along the DNA, and a mechanism for processivity based on topological linkage of the trimer to the DNA was proposed. Here, we have determined the crystal structure of λ exonuclease in complex with DNA at 1.88-Å resolution. The structure reveals that the enzyme unwinds the DNA prior to cleavage, such that two nucleotides of the 5'-ended strand insert into the active site of one subunit of the trimer, while the 3'-ended strand passes through the central channel to emerge out the back of the trimer. Unwinding of the DNA is facilitated by several apolar residues, including Leu78, that wedge into the base pairs at the single/double-strand junction to form favorable hydrophobic interactions. The terminal 5' phosphate of the DNA binds to a positively charged pocket buried at the end of the active site, while the scissile phosphate bridges two active site Mg(2+) ions. Our data suggest a mechanism for processivity in which wedging of Leu78 and other apolar residues into the base pairs of the DNA restricts backward movement, whereas attraction of the 5' phosphate to the positively charged pocket drives forward movement of the enzyme along the DNA at each cycle of the reaction. Thus, processivity of λ exonuclease operates not only at the level of the trimer, but also at the level of the monomer.


    Organizational Affiliation

    Ohio State Biochemistry Program and Department of Molecular and Cellular Biochemistry, The Ohio State University, 1645 Neil Avenue, Columbus, OH 43210, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure


Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Exonuclease
A, B, C
229Enterobacteria phage lambdaGene Names: exo (red-alpha, redX)
EC: 3.1.11.3
Find proteins for P03697 (Enterobacteria phage lambda)
Go to UniProtKB:  P03697
Entity ID: 2
MoleculeChainsLengthOrganism
5'-D(*GP*CP*GP*AP*CP*TP*AP*GP*TP*CP*GP*C)-3'D,E12N/A
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
PO4
Query on PO4

Download SDF File
Download CCD File
A, B, C
PHOSPHATE ION
O4 P
NBIIXXVUZAFLBC-UHFFFAOYSA-K
 Ligand Interaction
CL
Query on CL

Download SDF File
Download CCD File
B, C
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
 Ligand Interaction
CA
Query on CA

Download SDF File
Download CCD File
A, B, C
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.3 Å
  • R-Value Free: 0.281
  • R-Value Work: 0.211
  • Space Group: P 65
Unit Cell:
Length (Å)Angle (°)
a = 80.115α = 90.00
b = 80.115β = 90.00
c = 241.041γ = 120.00
Software Package:
Software NamePurpose
HKL-2000data reduction
PHASERphasing
HKL-2000data scaling
HKL-2000data collection
REFMACrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

  • Deposited Date: 2011-06-24
  • Released Date: 2011-07-20
  • Deposition Author(s): Bell, C.E., Zhang, J.

Revision History

  • Version 1.0: 2011-07-20
    Type: Initial release
  • Version 1.1: 2011-08-03
    Type: Data collection, Database references, Experimental preparation
