3RHY

Crystal structure of the dimethylarginine dimethylaminohydrolase adduct with 4-chloro-2-hydroxymethylpyridine


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.18 Å
  • R-Value Free: 0.265
  • R-Value Work: 0.209

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

On the mechanism of dimethylarginine dimethylaminohydrolase inactivation by 4-halopyridines.

Johnson, C.M.Monzingo, A.F.Ke, Z.Yoon, D.W.Linsky, T.W.Guo, H.Robertus, J.D.Fast, W.

(2011) J Am Chem Soc 133: 10951-10959

  • DOI: 10.1021/ja2033684
  • Primary Citation of Related Structures:
    3RHY

  • PubMed Abstract:
  • Small molecules capable of selective covalent protein modification are of significant interest for the development of biological probes and therapeutics. We recently reported that 2-methyl-4-bromopyridine is a quiescent affinity label for the nitric oxide controlling enzyme dimethylarginine dimethylaminohydrolase (DDAH) (Johnson, C ...

    Small molecules capable of selective covalent protein modification are of significant interest for the development of biological probes and therapeutics. We recently reported that 2-methyl-4-bromopyridine is a quiescent affinity label for the nitric oxide controlling enzyme dimethylarginine dimethylaminohydrolase (DDAH) (Johnson, C. M.; Linsky, T. W.; Yoon, D. W.; Person, M. D.; Fast, W. J. Am. Chem. Soc. 2011, 133, 1553-1562). Discovery of this novel protein modifier raised the possibility that the 4-halopyridine motif may be suitable for wider application. Therefore, the inactivation mechanism of the related compound 2-hydroxymethyl-4-chloropyridine is probed here in more detail. Solution studies support an inactivation mechanism in which the active site Asp66 residue stabilizes the pyridinium form of the inactivator, which has enhanced reactivity toward the active site Cys, resulting in covalent bond formation, loss of the halide, and irreversible inactivation. A 2.18 Å resolution X-ray crystal structure of the inactivated complex elucidates the orientation of the inactivator and its covalent attachment to the active site Cys, but the structural model does not show an interaction between the inactivator and Asp66. Molecular modeling is used to investigate inactivator binding, reaction, and also a final pyridinium deprotonation step that accounts for the apparent differences between the solution-based and structural studies with respect to the role of Asp66. This work integrates multiple approaches to elucidate the inactivation mechanism of a novel 4-halopyridine "warhead," emphasizing the strategy of using pyridinium formation as a "switch" to enhance reactivity when bound to the target protein.


    Organizational Affiliation

    Division of Medicinal Chemistry, College of Pharmacy, University of Texas, Austin, Texas 78712, USA.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
N(G),N(G)-dimethylarginine dimethylaminohydrolaseA, B254Pseudomonas aeruginosaMutation(s): 0
Gene Names: PA1195
EC: 3.5.3.18
UniProt
Find proteins for Q9I4E3 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1))
Explore Q9I4E3
Go to UniProtKB:  Q9I4E3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9I4E3
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
HM3
Query on HM3

Download Ideal Coordinates CCD File
C [auth A],
D [auth B]
(4-chloropyridin-2-yl)methanol
C6 H6 Cl N O
UEAIOHHGRGSGGJ-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.18 Å
  • R-Value Free: 0.265
  • R-Value Work: 0.209
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 45.8α = 90
b = 73.28β = 90
c = 149.53γ = 90
Software Package:
Software NamePurpose
StructureStudiodata collection
MOLREPphasing
CNSrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2011-06-15
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2011-07-27
    Changes: Database references
