Crystal structure of yeast Mmf1

Experimental Data Snapshot

  • Resolution: 1.75 Å
  • R-Value Free: 0.222
  • R-Value Work: 0.181
  • R-Value Observed: 0.183

wwPDB Validation   3D Report Full Report

This is version 1.3 of the entry. See complete history


Crystal structures and putative interface of Saccharomyces cerevisiae mitochondrial matrix proteins Mmf1 and Mam33.

Pu, Y.G.Jiang, Y.L.Ye, X.D.Ma, X.X.Guo, P.C.Lian, F.M.Teng, Y.B.Chen, Y.Zhou, C.Z.

(2011) J Struct Biol 175: 469-474

  • DOI: https://doi.org/10.1016/j.jsb.2011.05.005
  • Primary Citation of Related Structures:
    3QUW, 3QV0

  • PubMed Abstract:

    The yeast Saccharomyces cerevisiae mitochondrial matrix factor Mmf1, a member in the YER057c/Yigf/Uk114 family, participates in isoleucine biosynthesis and mitochondria maintenance. Mmf1 physically interacts with another mitochondrial matrix protein Mam33, which is involved in the sorting of cytochrome b₂ to the intermembrane space as well as mitochondrial ribosomal protein synthesis. To elucidate the structural basis for their interaction, we determined the crystal structures of Mmf1 and Mam33 at 1.74 and 2.10 Å, respectively. Both Mmf1 and Mam33 adopt a trimeric structure: each subunit of Mmf1 displays a chorismate mutase fold with a six-stranded β-sheet flanked by two α-helices on one side, whereas a subunit of Mam33 consists of a twisted six-stranded β-sheet surrounded by five α-helices. Biochemical assays combined with structure-based computational simulation enable us to model a putative complex of Mmf1-Mam33, which consists of one Mam33 trimer and two tandem Mmf1 trimers in a head-to-tail manner. The two interfaces between the ring-like trimers are mainly composed of electrostatic interactions mediated by complementary negatively and positively charged patches. These results provided the structural insights into the putative function of Mmf1 during mitochondrial protein synthesis via Mam33, a protein binding to mitochondrial ribosomal proteins.

  • Organizational Affiliation

    Hefei National Laboratory for Physical Sciences at Microscale and School of Life Sciences, People's Republic of China.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Protein MMF1153Saccharomyces cerevisiaeMutation(s): 0
Gene Names: IBM1MMF1YIL051C
Find proteins for P40185 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P40185
Go to UniProtKB:  P40185
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP40185
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 1.75 Å
  • R-Value Free: 0.222
  • R-Value Work: 0.181
  • R-Value Observed: 0.183
  • Space Group: H 3
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 77.618α = 90
b = 77.618β = 90
c = 43.911γ = 120
Software Package:
Software NamePurpose
MAR345dtbdata collection
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2011-06-08
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2011-08-17
    Changes: Database references
  • Version 1.3: 2023-09-13
    Changes: Data collection, Database references, Refinement description
