3N27 | pdb_00003n27

Molecular Basis of the Inhibition of Henipa Viruses

• PDB DOI: https://doi.org/10.2210/pdb3N27/pdb

• Classification: VIRAL PROTEIN
• Organism(s): Henipavirus nipahense, Henipavirus hendraense
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2010-05-17 Released: 2011-06-29
• Deposition Author(s): Liu, J., Lu, M.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free:
  0.242 (Depositor), 0.240 (DCC)
• R-Value Work:
  0.194 (Depositor), 0.190 (DCC)
• R-Value Observed:
  0.196 (Depositor)

Starting Model: experimental

Literature

Molecular Basis of the Inhibition of Henipa Viruses

Liu, J., Lu, M.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C3  (Explore in 3D)
Global Stoichiometry: Homo 3-mer - A3

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 26.69 kDa
• Atom Count: 1,917
• Modeled Residue Count: 222
• Deposited Residue Count: 240
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Fusion glycoprotein F0, linker, Fusion glycoprotein F0	A, B, C	80	Henipavirus nipahense, Henipavirus hendraense This entity is chimeric	Mutation(s): 0
UniProt
Find proteins for Q9IH63 (Nipah virus) Explore Q9IH63  Go to UniProtKB:  Q9IH63

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
CIT	D [auth A]	CITRIC ACID C6 H8 O7 KRKNYBCHXYNGOX-UHFFFAOYSA-N
TBU	E [auth A], F [auth C]	TERTIARY-BUTYL ALCOHOL C4 H10 O DKGAVHZHDRPRBM-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free:  0.242 (Depositor), 0.240 (DCC)
• R-Value Work:  0.194 (Depositor), 0.190 (DCC)
• R-Value Observed: 0.196 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 32.392	α = 90
b = 54.055	β = 90
c = 134.126	γ = 90

Software Package:

Software Name	Purpose
MAR345dtb	data collection
PHASER	phasing
REFMAC	refinement
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2011-06-29
Deposition Author(s): Liu, J., Lu, M.

Revision History

• Version 1.0: 2011-06-29
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 1.2: 2017-06-28
  Changes: Database references, Source and taxonomy, Structure summary
• Version 1.3: 2023-09-06
  Changes: Data collection, Database references, Derived calculations, Refinement description
