3LUL | pdb_00003lul

Crystal structure of Putative 4-amino-4-deoxychorismate lyase. (YP_094631.1) from Legionella pneumophila subsp. pneumophila str. Philadelphia 1 at 1.78 A resolution

• PDB DOI: https://doi.org/10.2210/pdb3LUL/pdb

• Classification: LYASE
• Organism(s): Legionella pneumophila subsp. pneumophila str. Philadelphia 1
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2010-02-17 Released: 2010-03-02
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.78 Å
• R-Value Free:
  0.201 (Depositor), 0.210 (DCC)
• R-Value Work:
  0.160 (Depositor), 0.170 (DCC)
• R-Value Observed:
  0.162 (Depositor)

Literature

Crystal structure of Putative 4-amino-4-deoxychorismate lyase. (YP_094631.1) from Legionella pneumophila subsp. pneumophila str. Philadelphia 1 at 1.78 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 63.04 kDa
• Atom Count: 5,049
• Modeled Residue Count: 537
• Deposited Residue Count: 544
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
4-amino-4-deoxychorismate lyase	A, B	272	Legionella pneumophila subsp. pneumophila str. Philadelphia 1	Mutation(s): 0  Gene Names: lpg0595 EC: 4.1.3.38 (UniProt), 2.6.1.42 (UniProt)
UniProt
Find proteins for Q5ZXY5 (Legionella pneumophila subsp. pneumophila (strain Philadelphia 1 / ATCC 33152 / DSM 7513)) Explore Q5ZXY5  Go to UniProtKB:  Q5ZXY5

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PO4	G [auth B]	PHOSPHATE ION O4 P NBIIXXVUZAFLBC-UHFFFAOYSA-K
EDO	C [auth A], D [auth A], E [auth A], F [auth B]	1,2-ETHANEDIOL C2 H6 O2 LYCAIKOWRPUZTN-UHFFFAOYSA-N

Modified Residues  2 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
LLP	A, B	L-PEPTIDE LINKING	C14 H22 N3 O7 P		LYS
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.78 Å
• R-Value Free:  0.201 (Depositor), 0.210 (DCC)
• R-Value Work:  0.160 (Depositor), 0.170 (DCC)
• R-Value Observed: 0.162 (Depositor)

Diffraction Data: https://doi.org/10.18430/M33LUL

Space Group: P 2₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 85.008	α = 90
b = 98.498	β = 90
c = 64.599	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SHELX	phasing
MolProbity	model building
XSCALE	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
SHELXD	phasing
autoSHARP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2010-03-02
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2010-03-02
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Version format compliance
• Version 1.2: 2017-11-08
  Changes: Refinement description
• Version 1.3: 2019-07-17
  Changes: Advisory, Data collection, Derived calculations, Refinement description
• Version 1.4: 2023-02-01
  Changes: Database references, Derived calculations
