Structure function studies of vaccinia virus host-range protein K1 reveal a novel ankyrin repeat interaction surface for K1s function

Experimental Data Snapshot

  • Resolution: 2.30 Å
  • R-Value Free: 0.254
  • R-Value Work: 0.210
  • R-Value Observed: 0.212

wwPDB Validation   3D Report Full Report

This is version 1.1 of the entry. See complete history


Structure function studies of vaccinia virus host range protein k1 reveal a novel functional surface for ankyrin repeat proteins.

Li, Y.Meng, X.Xiang, Y.Deng, J.

(2010) J Virol 84: 3331-3338

  • DOI: https://doi.org/10.1128/JVI.02332-09
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    Poxvirus host tropism at the cellular level is regulated by virus-encoded host range proteins acting downstream of virus entry. The functioning mechanisms of most host range proteins are unclear, but many contain multiple ankyrin (ANK) repeats, a motif that is known for ligand interaction through a concave surface. We report here the crystal structure of one of the ANK repeat-containing host range proteins, the vaccinia virus K1 protein. The structure, at a resolution of 2.3 A, showed that K1 consists entirely of ANK repeats, including seven complete ones and two incomplete ones, one each at the N and C terminus. Interestingly, Phe82 and Ser83, which were previously shown to be critical for K1's function, are solvent exposed and located on a convex surface, opposite the consensus ANK interaction surface. The importance of this convex surface was further supported by our additional mutagenesis studies. We found that K1's host range function was negatively affected by substitution of either Asn51 or Cys47 and completely abolished by substitution of both residues. Cys47 and Asn51 are also exposed on the convex surface, spatially adjacent to Phe82 and Ser83. Altogether, our data showed that K1 residues on a continuous convex ANK repeat surface are critical for the host range function, suggesting that K1 functions through ligand interaction and does so with a novel ANK interaction surface.

  • Organizational Affiliation

    Department of Microbiology and Immunology, University of Texas Health Science Center at San Antonio, 7703 Floyd Curl Dr., San Antonio, TX 78229, USA.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
A, B
285Vaccinia virusMutation(s): 0
Gene Names: K1L
Find proteins for Q6IV60 (Vaccinia virus)
Explore Q6IV60
Go to UniProtKB:  Q6IV60
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6IV60
Sequence Annotations
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
Query on MSE
A, B
Experimental Data & Validation

Experimental Data

  • Resolution: 2.30 Å
  • R-Value Free: 0.254
  • R-Value Work: 0.210
  • R-Value Observed: 0.212
  • Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 95.107α = 90
b = 110.263β = 90
c = 86.259γ = 90
Software Package:
Software NamePurpose
HKL-3000data collection
HKL-3000data reduction
SCALEPACKdata scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

  • Released Date: 2010-03-31
  • Deposition Author(s): Li, Y.

Revision History  (Full details and data files)

  • Version 1.0: 2010-03-31
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Advisory, Version format compliance
