3IVP | pdb_00003ivp

The structure of a possible transposon-related DNA-binding protein from Clostridium difficile 630.

PDB DOI: https://doi.org/10.2210/pdb3IVP/pdb

Classification: DNA BINDING PROTEIN
Organism(s): Clostridioides difficile 630
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2009-09-01 Released: 2009-09-22
Deposition Author(s): Tan, K., Marshall, N., Jedrzejczak, R., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.02 Å
R-Value Free:
0.235 (Depositor), 0.314 (DCC)
R-Value Work:
0.200 (Depositor), 0.293 (DCC)
R-Value Observed:
0.202 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3IVP

This is version 1.2 of the entry. See complete history.

Literature

The structure of a possible transposon-related DNA-binding protein from Clostridium difficile 630.

Tan, K., Marshall, N., Jedrzejczak, R., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 58.82 kDa
Atom Count: 3,805
Modeled Residue Count: 452
Deposited Residue Count: 504
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative transposon-related DNA-binding protein	A, B, C, D	126	Clostridioides difficile 630	Mutation(s): 0 Gene Names: CD3330, Clostridium difficile
UniProt
Find proteins for Q180H4 (Clostridioides difficile (strain 630)) Explore Q180H4 Go to UniProtKB: Q180H4
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q180H4
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PG4 Query on PG4 Download:Ideal Coordinates CCD File SDF format, chain G [auth D] SDF format, chain F [auth C] SDF format, chain E [auth C] MOL2 format, chain G [auth D] MOL2 format, chain F [auth C] MOL2 format, chain E [auth C] mmCIF format, chain G [auth D] mmCIF format, chain F [auth C] mmCIF format, chain E [auth C]	E [auth C], F [auth C], G [auth D]	TETRAETHYLENE GLYCOL C₈ H₁₈ O₅ UWHCKJMYHZGTIT-UHFFFAOYSA-N		Interactions Focus chain E [auth C] Focus chain F [auth C] Focus chain G [auth D] Interactions & Density Focus chain E [auth C] Focus chain F [auth C] Focus chain G [auth D]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B, C, D	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.02 Å
R-Value Free: 0.235 (Depositor), 0.314 (DCC)
R-Value Work: 0.200 (Depositor), 0.293 (DCC)
R-Value Observed: 0.202 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 49.326	α = 90
b = 69.829	β = 90
c = 170.359	γ = 90

Software Package:

Software Name	Purpose
SBC-Collect	data collection
SHELXD	phasing
MLPHARE	phasing
DM	model building
ARP	model building
WARP	model building
HKL-3000	phasing
REFMAC	refinement
HKL-3000	data reduction
HKL-3000	data scaling
DM	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2009-09-22

Deposition Author(s):

Jedrzejczak, R.

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2009-09-22
Type: Initial release
Version 1.1: 2011-07-13
Changes: Advisory, Refinement description, Source and taxonomy, Version format compliance
Version 1.2: 2024-10-16
Changes: Data collection, Database references, Derived calculations, Structure summary
