3I8B

The crystal structure of xylulose kinase from Bifidobacterium adolescentis

• PDB DOI: https://doi.org/10.2210/pdb3I8B/pdb

• Classification: TRANSFERASE
• Organism(s): Bifidobacterium adolescentis ATCC 15703
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2009-07-09 Released: 2009-08-04
• Deposition Author(s): Zhang, Z., Burley, S.K., Swaminathan, S., New York SGX Research Center for Structural Genomics (NYSGXRC)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free: 0.226
• R-Value Work: 0.180
• R-Value Observed: 0.183

Literature

The crystal structure of xylulose kinase from Bifidobacterium adolescentis

Zhang, Z., Burley, S.K., Swaminathan, S.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 54.26 kDa
• Atom Count: 4,083
• Modelled Residue Count: 506
• Deposited Residue Count: 515
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Xylulose kinase	A	515	Bifidobacterium adolescentis ATCC 15703	Mutation(s): 0  Gene Names: xylB EC: 2.7.1.17
UniProt
Find proteins for A1A0I0 (Bifidobacterium adolescentis (strain ATCC 15703 / DSM 20083 / NCTC 11814 / E194a)) Explore A1A0I0  Go to UniProtKB:  A1A0I0

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
MG	B [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free: 0.226
• R-Value Work: 0.180
• R-Value Observed: 0.183
• Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 96.732	α = 90
b = 61.918	β = 93.04
c = 94.606	γ = 90

Software Package:

Software Name	Purpose
CBASS	data collection
SOLVE	phasing
PHENIX	refinement
MOSFLM	data reduction
SCALA	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2009-08-04
Deposition Author(s): Zhang, Z., Burley, S.K., Swaminathan, S., New York SGX Research Center for Structural Genomics (NYSGXRC)

Revision History

• Version 1.0: 2009-08-04
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 1.2: 2021-02-10
  Changes: Database references, Derived calculations, Structure summary
• Version 1.3: 2024-11-20
  Changes: Data collection, Database references, Structure summary
