3GIW | pdb_00003giw

CRYSTAL STRUCTURE OF a DUF574 family protein (SAV_2177) FROM STREPTOMYCES AVERMITILIS MA-4680 AT 1.45 A RESOLUTION

• PDB DOI: https://doi.org/10.2210/pdb3GIW/pdb

• Classification: UNKNOWN FUNCTION
• Organism(s): Streptomyces avermitilis MA-4680 = NBRC 14893
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2009-03-06 Released: 2009-04-14
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.45 Å
• R-Value Free:
  0.176 (Depositor), 0.180 (DCC)
• R-Value Work:
  0.156 (Depositor), 0.160 (DCC)
• R-Value Observed:
  0.157 (Depositor)

Literature

Crystal structure of Rossmann-fold protein of unknown function (DUF574) (NP_823353.1) from Streptomyces avermitilis MA-4680 at 1.45 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 30.88 kDa
• Atom Count: 2,451
• Modeled Residue Count: 262
• Deposited Residue Count: 277
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Protein of unknown function DUF574	A	277	Streptomyces avermitilis MA-4680 = NBRC 14893	Mutation(s): 0  Gene Names: NP_823353.1, SAV2177, SAV_2177
UniProt
Find proteins for Q82L35 (Streptomyces avermitilis (strain ATCC 31267 / DSM 46492 / JCM 5070 / NBRC 14893 / NCIMB 12804 / NRRL 8165 / MA-4680)) Explore Q82L35  Go to UniProtKB:  Q82L35

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
GOL	C [auth A], D [auth A]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N
UNL	B [auth A]	Unknown ligand PEDCQBHIVMGVHV-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.45 Å
• R-Value Free:  0.176 (Depositor), 0.180 (DCC)
• R-Value Work:  0.156 (Depositor), 0.160 (DCC)
• R-Value Observed: 0.157 (Depositor)

Diffraction Data: https://doi.org/10.18430/M33GIW

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 129.716	α = 90
b = 49.669	β = 94.72
c = 45.132	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SHELX	phasing
MolProbity	model building
XSCALE	data scaling
PDB_EXTRACT	data extraction
MAR345	data collection
XDS	data reduction
SHELXD	phasing
autoSHARP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2009-04-14
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2009-04-14
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Source and taxonomy, Version format compliance
• Version 1.2: 2017-11-01
  Changes: Refinement description
• Version 1.3: 2019-07-24
  Changes: Data collection, Derived calculations, Refinement description
• Version 1.4: 2023-02-01
  Changes: Database references, Derived calculations
• Version 1.5: 2024-10-09
  Changes: Data collection, Structure summary
