3F7S | pdb_00003f7s

CRYSTAL STRUCTURE OF A NTF2-LIKE PROTEIN OF UNKNOWN FUNCTION (PP_4556) FROM PSEUDOMONAS PUTIDA KT2440 AT 2.11 A RESOLUTION

• PDB DOI: https://doi.org/10.2210/pdb3F7S/pdb

• Classification: UNKNOWN FUNCTION
• Organism(s): Pseudomonas putida KT2440
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2008-11-10 Released: 2008-11-25
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.11 Å
• R-Value Free:
  0.217 (Depositor), 0.220 (DCC)
• R-Value Work:
  0.177 (Depositor), 0.180 (DCC)
• R-Value Observed:
  0.179 (Depositor)

Literature

Crystal structure of NTF2-like protein of unknown function (NP_746665.1) from PSEUDOMONAS PUTIDA KT2440 at 2.11 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 16.5 kDa
• Atom Count: 1,179
• Modeled Residue Count: 142
• Deposited Residue Count: 142
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
uncharacterized NTF2-like protein	A	142	Pseudomonas putida KT2440	Mutation(s): 0  Gene Names: NP_746665.1, PP4556, PP_4556
UniProt
Find proteins for Q88EB0 (Pseudomonas putida (strain ATCC 47054 / DSM 6125 / CFBP 8728 / NCIMB 11950 / KT2440)) Explore Q88EB0  Go to UniProtKB:  Q88EB0

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SO4	C [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
GOL	D [auth A]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N
UNL	B [auth A]	Unknown ligand PEDCQBHIVMGVHV-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.11 Å
• R-Value Free:  0.217 (Depositor), 0.220 (DCC)
• R-Value Work:  0.177 (Depositor), 0.180 (DCC)
• R-Value Observed: 0.179 (Depositor)

Diffraction Data: https://doi.org/10.18430/M33F7S

Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 65.92	α = 90
b = 65.92	β = 90
c = 89.39	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SHELX	phasing
MolProbity	model building
XSCALE	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
SHELXD	phasing
autoSHARP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2008-11-25
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2008-11-25
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Refinement description, Version format compliance
• Version 1.2: 2017-10-25
  Changes: Refinement description
• Version 1.3: 2019-07-24
  Changes: Data collection, Derived calculations, Refinement description
• Version 1.4: 2023-02-01
  Changes: Database references, Derived calculations
• Version 1.5: 2024-11-20
  Changes: Data collection, Structure summary
