3BYL | pdb_00003byl

Crystal structure of B. subtilis levansucrase mutant E342A

PDB DOI: https://doi.org/10.2210/pdb3BYL/pdb

Classification: TRANSFERASE
Organism(s): Bacillus subtilis
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2008-01-16 Released: 2008-02-12
Deposition Author(s): Futterer, K., Meng, G.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free:
0.222 (Depositor), 0.226 (DCC)
R-Value Work:
0.180 (Depositor), 0.186 (DCC)
R-Value Observed:
0.182 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 3BYL

This is version 1.3 of the entry. See complete history.

Literature

Donor substrate recognition in the raffinose-bound E342A mutant of fructosyltransferase Bacillus subtilis levansucrase

Meng, G., Futterer, K.

To be published.

Macromolecule Content

Total Structure Weight: 52.97 kDa
Atom Count: 3,704
Modeled Residue Count: 440
Deposited Residue Count: 473
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Levansucrase	A	473	Bacillus subtilis	Mutation(s): 1 Gene Names: SACB EC: 2.4.1.10
UniProt
Find proteins for P05655 (Bacillus subtilis (strain 168)) Explore P05655 Go to UniProtKB: P05655
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P05655
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free: 0.222 (Depositor), 0.226 (DCC)
R-Value Work: 0.180 (Depositor), 0.186 (DCC)
R-Value Observed: 0.182 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 51.133	α = 90
b = 67.281	β = 90
c = 123.622	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PDB_EXTRACT	data extraction
DENZO	data reduction
SCALEPACK	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2008-02-12

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2008-02-12
Type: Initial release
Version 1.1: 2011-07-13
Changes: Advisory, Version format compliance
Version 1.2: 2021-11-10
Changes: Database references
Version 1.3: 2023-11-01
Changes: Data collection, Refinement description
