3ALF

Crystal Structure of Class V Chitinase from Nicotiana tobaccum


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.2 Å
  • R-Value Free: 0.187
  • R-Value Work: 0.176

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Crystal structure and mode of action of a class V chitinase from Nicotiana tabacum

Ohnuma, T.Numata, T.Osawa, T.Mizuhara, M.Varum, K.M.Fukamizo, T.

(2011) Plant Mol.Biol. 75: 291-304

  • DOI: 10.1007/s11103-010-9727-z
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • A class V chitinase from Nicotiana tabacum (NtChiV) with amino acid sequence similar to that of Serratia marcescens chitinase B (SmChiB) was expressed in E. coli and purified to homogeneity. When N-acetylglucosamine oligosaccharides [(NAG)(n)] were h ...

    A class V chitinase from Nicotiana tabacum (NtChiV) with amino acid sequence similar to that of Serratia marcescens chitinase B (SmChiB) was expressed in E. coli and purified to homogeneity. When N-acetylglucosamine oligosaccharides [(NAG)(n)] were hydrolyzed by the purified NtChiV, the second glycosidic linkage from the non-reducing end was predominantly hydrolyzed in a manner similar to that of SmChiB. NtChiV was shown to hydrolyze partially N-acetylated chitosan non-processively, whereas SmChiB hydrolyzes the same substrate processively. The crystal structure of NtChiV was determined by the single-wavelength anomalous dispersion method at 1.2 Å resolution. The protein adopts a classical (β/α)₈-barrel fold (residues 1-233 and 303-348) with an insertion of a small (α + β) domain (residues 234-302). This is the first crystal structure of a plant class V chitinase. The crystal structure of the inactive mutant NtChiV E115Q complexed with (NAG)₄ was also solved and exhibited a linear conformation of the bound oligosaccharide occupying -2, +1, +2, and +3 subsites. The complex structure corresponds to an initial state of (NAG)₄ binding, which is proposed to be converted into a bent conformation through sliding of the +1, +2, and +3 sugar units to -1, +1, and +2 subsites. Although NtChiV is similar to SmChiB, the chitin-binding domain is present in the C-terminus of the latter, but not in the former. Aromatic amino acid residues found in the substrate binding cleft of SmChiB, including Trp97, are substituted with aliphatic residues in NtChiV. These structural differences appear to be responsible for NtChiV being a non-processive enzyme.


    Organizational Affiliation

    Department of Advanced Bioscience, Kinki University, 3327-204 Nakamachi, Nara 631-8505, Japan.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Chitinase, class V
A
353Nicotiana tabacumMutation(s): 0
Gene Names: chi-V (LOC107790755)
Find proteins for Q43576 (Nicotiana tabacum)
Go to UniProtKB:  Q43576
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
PO4
Query on PO4

Download SDF File
Download CCD File
A
PHOSPHATE ION
O4 P
NBIIXXVUZAFLBC-UHFFFAOYSA-K
 Ligand Interaction
EDO
Query on EDO

Download SDF File
Download CCD File
A
1,2-ETHANEDIOL
ETHYLENE GLYCOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.2 Å
  • R-Value Free: 0.187
  • R-Value Work: 0.176
  • Space Group: P 21 21 2
Unit Cell:
Length (Å)Angle (°)
a = 62.395α = 90.00
b = 120.292β = 90.00
c = 51.912γ = 90.00
Software Package:
Software NamePurpose
CNSrefinement
HKL-2000data reduction
HKL-2000data scaling
HKL-2000data collection
SHARPphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2011-03-23
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Version format compliance
