3ZQI

Structure of Tetracycline repressor in complex with inducer peptide- TIP2


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.5 Å
  • R-Value Free: 0.195
  • R-Value Work: 0.160

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

An Exclusive Alpha/Beta Code Directs Allostery in Tetr-Peptide Complexes.

Sevvana, M.Goetz, C.Goeke, D.Wimmer, C.Berens, C.Hillen, W.Muller, Y.A.

(2012) J.Mol.Biol. 416: 46

  • DOI: 10.1016/j.jmb.2011.12.008
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • The allosteric mechanism of one of the best characterized bacterial transcription regulators, tetracycline repressor (TetR), has recently been questioned. Tetracycline binding induces cooperative folding of TetR, as suggested by recent unfolding stud ...

    The allosteric mechanism of one of the best characterized bacterial transcription regulators, tetracycline repressor (TetR), has recently been questioned. Tetracycline binding induces cooperative folding of TetR, as suggested by recent unfolding studies, rather than switching between two defined conformational states, namely a DNA-binding-competent conformation and a non-DNA-binding conformation. Upon ligand binding, a host of near-native multiconformational structures collapse into a single, highly stabilized protein conformation that is no longer able to bind DNA. Here, structure-function studies performed with four synthetic peptides that bind to TetR and mimic the function of low-molecular-weight effectors, such as tetracyclines, provide new means to discriminate between different allosteric models. Whereas two inducing peptides bind in an extended β-like conformation, two anti-inducing peptides form an α-helix in the effector binding site of TetR. This exclusive bimodal interaction mode coincides with two distinct overall conformations of TetR, namely one that is identical with induced TetR and one that mirrors the DNA-bound state of TetR. Urea-induced unfolding studies show no increase in thermodynamic stability for any of the peptide complexes, although fluorescence measurements demonstrate peptide binding to TetR. This strongly suggests that, at least for these peptide effectors, a classical two-state allosteric model best describes TetR function.


    Organizational Affiliation

    Lehrstuhl für Biotechnik, Department of Biology, Friedrich-Alexander University Erlangen-Nuremberg, Henkestr. 91, D-91052 Erlangen, Germany.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
TETRACYCLINE REPRESSOR PROTEIN CLASS B FROM TRANSPOSON TN10, TETRACYCLINE REPRESSOR PROTEIN CLASS D
A, B
208Escherichia coliMutation(s): 4
Gene Names: tetR, tetR
Find proteins for P04483 (Escherichia coli)
Go to UniProtKB:  P04483
Find proteins for P0ACT4 (Escherichia coli)
Go to UniProtKB:  P0ACT4
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
INDUCER PEPTIDE TIP2
C, D
16N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
EDO
Query on EDO

Download SDF File
Download CCD File
A, B
1,2-ETHANEDIOL
ETHYLENE GLYCOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
 Ligand Interaction
PG4
Query on PG4

Download SDF File
Download CCD File
B
TETRAETHYLENE GLYCOL
C8 H18 O5
UWHCKJMYHZGTIT-UHFFFAOYSA-N
 Ligand Interaction
MG
Query on MG

Download SDF File
Download CCD File
A
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.5 Å
  • R-Value Free: 0.195
  • R-Value Work: 0.160
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 56.700α = 90.00
b = 78.560β = 90.00
c = 103.880γ = 90.00
Software Package:
Software NamePurpose
REFMACrefinement
XSCALEdata scaling
PHASERphasing
XDSdata reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2011-12-28
    Type: Initial release
  • Version 1.1: 2012-02-08
    Type: Other
  • Version 1.2: 2017-03-15
    Type: Source and taxonomy
