3ZKK

Structure of the xylo-oligosaccharide specific solute binding protein from Bifidobacterium animalis subsp. lactis Bl-04 in complex with xylotetraose


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.198 Å
  • R-Value Free: 0.244
  • R-Value Work: 0.201

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history

Literature

Structural Basis for Arabinoxylo-Oligosaccharide Capture by the Probiotic Bifidobacterium Animalis Subsp. Lactis Bl-04

Ejby, M.Fredslund, F.Vujicic-Zagar, A.Svensson, B.Slotboom, D.J.Abou Hachem, M.

(2013) Mol.Microbiol. 90: 1100

  • DOI: 10.1111/mmi.12419
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Glycan utilization plays a key role in modulating the composition of the gut microbiota, but molecular insight into oligosaccharide uptake by this microbial community is lacking. Arabinoxylo-oligosaccharides (AXOS) are abundant in the diet, and are s ...

    Glycan utilization plays a key role in modulating the composition of the gut microbiota, but molecular insight into oligosaccharide uptake by this microbial community is lacking. Arabinoxylo-oligosaccharides (AXOS) are abundant in the diet, and are selectively fermented by probiotic bifidobacteria in the colon. Here we show how selectivity for AXOS uptake is established by the probiotic strain Bifidobacterium animalis subsp. lactis Bl-04. The binding protein BlAXBP, which is associated with an ATP-binding cassette (ABC) transporter that mediates the uptake of AXOS, displays an exceptionally broad specificity for arabinosyl-decorated and undecorated xylo-oligosaccharides, with preference for tri- and tetra-saccharides. Crystal structures of BlAXBP in complex with four different ligands revealed the basis for this versatility. Uniquely, the protein was able to recognize oligosaccharides in two opposite orientations, which facilitates the optimization of interactions with the various ligands. Broad substrate specificity was further enhanced by a spacious binding pocket accommodating decorations at different mainchain positions and conformational flexibility of a lid-like loop. Phylogenetic and genetic analyses show that BlAXBP is highly conserved within Bifidobacterium, but is lacking in other gut microbiota members. These data indicate niche adaptation within Bifidobacterium and highlight the metabolic syntrophy (cross-feeding) among the gut microbiota.


    Organizational Affiliation

    Enzyme and Protein Chemistry, Department of Systems Biology, Technical University of Denmark, Søltofts Plads, Building 224, DK-2800, Kgs. Lyngby, Denmark.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
XOS BINDING PROTEIN
A
413N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
P33
Query on P33

Download SDF File
Download CCD File
A
3,6,9,12,15,18-HEXAOXAICOSANE-1,20-DIOL
HEPTAETHYLENE GLYCOL, PEG330
C14 H30 O8
XPJRQAIZZQMSCM-UHFFFAOYSA-N
 Ligand Interaction
XYP
Query on XYP

Download SDF File
Download CCD File
A
BETA-D-XYLOPYRANOSE
C5 H10 O5
SRBFZHDQGSBBOR-KKQCNMDGSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.198 Å
  • R-Value Free: 0.244
  • R-Value Work: 0.201
  • Space Group: P 21 21 2
Unit Cell:
Length (Å)Angle (°)
a = 68.045α = 90.00
b = 124.049β = 90.00
c = 61.334γ = 90.00
Software Package:
Software NamePurpose
XDSdata reduction
XSCALEdata scaling
PHENIXrefinement
PHASERphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2013-10-30
    Type: Initial release
  • Version 1.1: 2013-12-11
    Type: Database references
  • Version 1.2: 2019-01-30
    Type: Data collection, Experimental preparation
  • Version 1.3: 2019-02-06
    Type: Data collection, Experimental preparation
