3X2Z | pdb_00003x2z

Crystal structure of metallo-beta-lactamase in complex with nickel from Thermotoga maritima

PDB DOI: https://doi.org/10.2210/pdb3X2Z/pdb

Classification: HYDROLASE
Organism(s): Thermotoga maritima MSB8
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2015-01-07 Released: 2016-02-17
Deposition Author(s): Choi, H.J., Kim, H.J., Matsuura, A., Mikami, B., Yoon, H.J., Lee, H.H.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.33 Å
R-Value Free:
0.205 (Depositor), 0.209 (DCC)
R-Value Work:
0.191 (Depositor), 0.194 (DCC)
R-Value Observed:
0.191 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3X2Z

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of metallo-beta-lactamase in complex with nickel from Thermotoga maritima

Choi, H.J., Kim, H.J., Matsuura, A., Mikami, B., Yoon, H.J., Lee, H.H.

To be published.

Macromolecule Content

Total Structure Weight: 74.55 kDa
Atom Count: 5,534
Modeled Residue Count: 681
Deposited Residue Count: 681
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
UPF0173 metal-dependent hydrolase TM_1162	A, B, C	227	Thermotoga maritima MSB8	Mutation(s): 0 Gene Names: TM_1162
UniProt
Find proteins for Q9X0P5 (Thermotoga maritima (strain ATCC 43589 / DSM 3109 / JCM 10099 / NBRC 100826 / MSB8)) Explore Q9X0P5 Go to UniProtKB: Q9X0P5
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9X0P5
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NI Query on NI Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth B] SDF format, chain G [auth B] SDF format, chain H [auth C] SDF format, chain I [auth C] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth B] MOL2 format, chain G [auth B] MOL2 format, chain H [auth C] MOL2 format, chain I [auth C] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth B] mmCIF format, chain G [auth B] mmCIF format, chain H [auth C] mmCIF format, chain I [auth C]	D [auth A] E [auth A] F [auth B] G [auth B] H [auth C] D [auth A], E [auth A], F [auth B], G [auth B], H [auth C], I [auth C]	NICKEL (II) ION Ni VEQPNABPJHWNSG-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth B] Focus chain G [auth B] Focus chain H [auth C] Focus chain I [auth C] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth B] Focus chain G [auth B] Focus chain H [auth C] Focus chain I [auth C]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.33 Å
R-Value Free: 0.205 (Depositor), 0.209 (DCC)
R-Value Work: 0.191 (Depositor), 0.194 (DCC)
R-Value Observed: 0.191 (Depositor)

Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 143.538	α = 90
b = 143.538	β = 90
c = 149.853	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data collection
CCP4	model building
REFMAC	refinement
HKL-2000	data reduction
HKL-2000	data scaling
CCP4	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2016-02-17

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2016-02-17
Type: Initial release
Version 1.1: 2024-03-20
Changes: Data collection, Database references, Derived calculations
