3X14

Crystal structure of HLA-B*0801.N80I.R82L.G83R


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.229
  • R-Value Work: 0.178
  • R-Value Observed: 0.180

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

The interaction of KIR3DL1*001 with HLA class I molecules is dependent upon molecular microarchitecture within the Bw4 epitope

Saunders, P.M.Vivian, J.P.Baschuk, N.Beddoe, T.Widjaja, J.O'Connor, G.M.Hitchen, C.Pymm, P.Andrews, D.M.Gras, S.McVicar, D.W.Rossjohn, J.Brooks, A.G.

(2015) J Immunol 194: 781-789

  • DOI: 10.4049/jimmunol.1402542
  • Primary Citation of Related Structures:
    3X14, 3X11, 3X12, 3X13

  • PubMed Abstract:
  • The killer cell Ig-like receptor 3DL1 (KIR3DL1) inhibits activation of NK cells upon interaction with HLA class I molecules such as HLA-B*57:01, which contains the Bw4 epitope spanning residues 77-83 (e.g., NLRIALR), and not with HLA allomorphs that ...

    The killer cell Ig-like receptor 3DL1 (KIR3DL1) inhibits activation of NK cells upon interaction with HLA class I molecules such as HLA-B*57:01, which contains the Bw4 epitope spanning residues 77-83 (e.g., NLRIALR), and not with HLA allomorphs that possess the Bw6 motif (e.g., HLA-B*08:01), which differ at residues 77, 80, 81, 82, and 83. Although Bw4 residues Ile(80) and Arg(83) directly interact with KIR3DL1*001, their precise role in determining KIR3DL1-HLA-Bw4 specificity remains unclear. Recognition of HLA-B*57:01 by either KIR3DL1(+) NK cells or the NK cell line YTS transfected with KIR3DL1*001 was impaired by mutation of residues 80 and 83 of HLA-B*57:01 to the corresponding amino acids within the Bw6 motif. Conversely, the simultaneous introduction of three Bw4 residues at positions 80, 82, and 83 into HLA-B*08:01 conferred an interaction with KIR3DL1*001. Structural analysis of HLA-B*57:01, HLA-B*08:01, and mutants of each bearing substitutions at positions 80 and 83 revealed that Ile(80) and Arg(83) within the Bw4 motif constrain the conformation of Glu(76), primarily through a salt bridge between Arg(83) and Glu(76). This salt bridge was absent in HLA-Bw6 molecules as well as position 83 mutants of HLA-B*57:01. Mutation of the Bw4 residue Ile(80) also disrupted this salt bridge, providing further insight into the role that position 80 plays in mediating KIR3DL1 recognition. Thus, the strict conformation of HLA-Bw4 allotypes, held in place by the Glu(76)-Arg(83) interaction, facilitates KIR3DL1 binding, whereas Bw6 allotypes present a platform on the α1 helix that is less permissive for KIR3DL1 binding.


    Organizational Affiliation

    Department of Microbiology and Immunology, Peter Doherty Institute for Infection and Immunity, The University of Melbourne, Parkville, Victoria 3010, Australia.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
HLA class I histocompatibility antigen, B-8 alpha chainA276Homo sapiensMutation(s): 3
Gene Names: HLA-BHLAB
Find proteins for P01889 (Homo sapiens)
Explore P01889
Go to UniProtKB:  P01889
NIH Common Fund Data Resources
PHAROS  P01889
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Beta-2-microglobulinB99Homo sapiensMutation(s): 0
Gene Names: B2MCDABP0092HDCMA22P
Find proteins for P61769 (Homo sapiens)
Explore P61769
Go to UniProtKB:  P61769
NIH Common Fund Data Resources
PHAROS  P61769
Protein Feature View
Expand
  • Reference Sequence
  • Find similar proteins by:  Sequence   |   Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
peptideC9Human herpesvirus 4 strain B95-8Mutation(s): 0
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.229
  • R-Value Work: 0.178
  • R-Value Observed: 0.180
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 50.272α = 90
b = 80.761β = 90
c = 106.605γ = 90
Software Package:
Software NamePurpose
Blu-Icedata collection
PHASERphasing
BUSTERrefinement
MOSFLMdata reduction
SCALAdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2014-12-24
    Type: Initial release
  • Version 1.1: 2015-04-08
    Changes: Database references
