3X0W | pdb_00003x0w

Crystal structure of PLEKHM1 LIR-fused human LC3B_2-119


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.71 Å
  • R-Value Free:
    0.294 (Depositor), 0.294 (DCC)
  • R-Value Work:
    0.224 (Depositor), 0.229 (DCC)
  • R-Value Observed:
    0.228 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 3X0W

This is version 1.2 of the entry. See complete history

Literature

PLEKHM1 regulates autophagosome-lysosome fusion through HOPS complex and LC3/GABARAP proteins.

McEwan, D.G.Popovic, D.Gubas, A.Terawaki, S.Suzuki, H.Stadel, D.Coxon, F.P.Miranda de Stegmann, D.Bhogaraju, S.Maddi, K.Kirchof, A.Gatti, E.Helfrich, M.H.Wakatsuki, S.Behrends, C.Pierre, P.Dikic, I.

(2015) Mol Cell 57: 39-54

  • DOI: https://doi.org/10.1016/j.molcel.2014.11.006
  • Primary Citation Related Structures:
    3X0W

  • PubMed Abstract:

    The lysosome is the final destination for degradation of endocytic cargo, plasma membrane constituents, and intracellular components sequestered by macroautophagy. Fusion of endosomes and autophagosomes with the lysosome depends on the GTPase Rab7 and the homotypic fusion and protein sorting (HOPS) complex, but adaptor proteins that link endocytic and autophagy pathways with lysosomes are poorly characterized. Herein, we show that Pleckstrin homology domain containing protein family member 1 (PLEKHM1) directly interacts with HOPS complex and contains a LC3-interacting region (LIR) that mediates its binding to autophagosomal membranes. Depletion of PLEKHM1 blocks lysosomal degradation of endocytic (EGFR) cargo and enhances presentation of MHC class I molecules. Moreover, genetic loss of PLEKHM1 impedes autophagy flux upon mTOR inhibition and PLEKHM1 regulates clearance of protein aggregates in an autophagy- and LIR-dependent manner. PLEKHM1 is thus a multivalent endocytic adaptor involved in the lysosome fusion events controlling selective and nonselective autophagy pathways.


  • Organizational Affiliation
    • Institute of Biochemistry II, Goethe University School of Medicine, Theodor-Stern-Kai 7, D-60590 Frankfurt (Main), Germany.

Macromolecule Content

  • Total Structure Weight: 31.46 kDa
  • Atom Count: 2,068
  • Modeled Residue Count: 247
  • Deposited Residue Count: 268
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Microtubule-associated proteins 1A/1B light chain 3B
A, B
134Homo sapiensMutation(s): 0
Gene Names: MAP1LC3BMAP1ALC3
UniProt & NIH Common Fund Data Resources
Find proteins for Q9GZQ8 (Homo sapiens)
Explore Q9GZQ8
Go to UniProtKB:  Q9GZQ8
PHAROS:  Q9GZQ8
GTEx:  ENSG00000140941
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9GZQ8
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.71 Å
  • R-Value Free:  0.294 (Depositor), 0.294 (DCC)
  • R-Value Work:  0.224 (Depositor), 0.229 (DCC)
  • R-Value Observed: 0.228 (Depositor)
Space Group: P 43 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 69.009α = 90
b = 69.009β = 90
c = 119.244γ = 90
Software Package:
Software NamePurpose
MOLREPphasing
REFMACrefinement
XDSdata reduction
SCALAdata scaling

Structure Validation

View Full Validation Report



Entry History

Revision History  (Full details and data files)

  • Version 1.0: 2015-01-14
    Type: Initial release
  • Version 1.1: 2022-08-24
    Changes: Database references
  • Version 1.2: 2023-11-08
    Changes: Data collection, Refinement description
