3WBR

Crystal structure of carbohydrate recognition domain of Blood Dendritic Cell Antigen-2 (BDCA2) lectin (crystal form-3)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.295
  • R-Value Work: 0.253
  • R-Value Observed: 0.255

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Crystal structures of carbohydrate recognition domain of blood dendritic cell antigen-2 (BDCA2) reveal a common domain-swapped dimer

Nagae, M.Ikeda, A.Kitago, Y.Matsumoto, N.Yamamoto, K.Yamaguchi, Y.

(2013) Proteins

  • DOI: 10.1002/prot.24504
  • Primary Citation of Related Structures:
    3WBP, 3WBQ, 3WBR

  • PubMed Abstract:
  • We report on crystal structures of a carbohydrate recognition domain (CRD) of human C-type lectin receptor blood dendritic cell antigen-2 (BDCA2). Three different crystal forms were obtained at 1.8-2.3 Å resolution. In all three, the CRD has a basic ...

    We report on crystal structures of a carbohydrate recognition domain (CRD) of human C-type lectin receptor blood dendritic cell antigen-2 (BDCA2). Three different crystal forms were obtained at 1.8-2.3 Å resolution. In all three, the CRD has a basic C-type lectin fold, but a long loop extends away from the core domain to form a domain-swapped dimer. The structures of the dimers from the three different crystal forms superimpose well, indicating that domain swapping and dimer formation are energetically stable. The structure of the dimer is compared with other domain-swapped proteins, and a possible regulation mechanism of BDCA2 is discussed.


    Organizational Affiliation

    Structural Glycobiology Team, Systems Glycobiology Research Group, RIKEN-Max Planck Joint Research Center, RIKEN Global Research Cluster, Wako, Saitama, 351-0198, Japan.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
C-type lectin domain family 4 member CABCDEFGH130Homo sapiensMutation(s): 0
Gene Names: BDCA2CLEC4CCLECSF11CLECSF7DLECHECLUNQ9361/PRO34150
Find proteins for Q8WTT0 (Homo sapiens)
Explore Q8WTT0
Go to UniProtKB:  Q8WTT0
NIH Common Fund Data Resources
PHAROS  Q8WTT0
Protein Feature View
Expand
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.295
  • R-Value Work: 0.253
  • R-Value Observed: 0.255
  • Space Group: P 43 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 86.13α = 90
b = 86.13β = 90
c = 431.71γ = 90
Software Package:
Software NamePurpose
SERGUIdata collection
MOLREPphasing
REFMACrefinement
XDSdata reduction
XDSdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2013-12-25
    Type: Initial release
  • Version 1.1: 2014-04-09
    Changes: Database references
  • Version 1.2: 2017-11-22
    Changes: Refinement description
