3W20

Crystal Structure of a Novel N-Substituted L-Amino Acid Dioxygenase from Burkholderia ambifaria AMMD


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.77 Å
  • R-Value Free: 0.241
  • R-Value Work: 0.211

wwPDB Validation 3D Report Full Report


This is version 1.0 of the entry. See complete history

Literature

Crystal Structure of a Novel N-Substituted L-Amino Acid Dioxygenase from Burkholderia ambifaria AMMD

Qin, H.M.Miyakawa, T.Jia, M.Z.Nakamura, A.Ohtsuka, J.Xue, Y.L.Kawashima, T.Kasahara, T.Hibi, M.Ogawa, J.Tanokura, M.

(2013) Plos One 8: e63996-e63996

  • DOI: 10.1371/journal.pone.0063996
  • Primary Citation of Related Structures:  3W21

  • PubMed Abstract:
  • A novel dioxygenase from Burkholderia ambifaria AMMD (SadA) stereoselectively catalyzes the C3-hydroxylation of N-substituted branched-chain or aromatic L-amino acids, especially N-succinyl-L-leucine, coupled with the conversion of α-ketoglutarate to ...

    A novel dioxygenase from Burkholderia ambifaria AMMD (SadA) stereoselectively catalyzes the C3-hydroxylation of N-substituted branched-chain or aromatic L-amino acids, especially N-succinyl-L-leucine, coupled with the conversion of α-ketoglutarate to succinate and CO2. To elucidate the structural basis of the substrate specificity and stereoselective hydroxylation, we determined the crystal structures of the SadA.Zn(II) and SadA.Zn(II).α-KG complexes at 1.77 Å and 1.98 Å resolutions, respectively. SadA adopted a double-stranded β-helix fold at the core of the structure. In addition, an HXD/EXnH motif in the active site coordinated a Zn(II) as a substitute for Fe(II). The α-KG molecule also coordinated Zn(II) in a bidentate manner via its 1-carboxylate and 2-oxo groups. Based on the SadA.Zn(II).α-KG structure and mutation analyses, we constructed substrate-binding models with N-succinyl-L-leucine and N-succinyl-L-phenylalanine, which provided new insight into the substrate specificity. The results will be useful for the rational design of SadA variants aimed at the recognition of various N-succinyl L-amino acids.


    Organizational Affiliation

    Department of Applied Biological Chemistry, Graduate School of Agricultural and Life Sciences, The University of Tokyo, Tokyo, Japan.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Putative uncharacterized protein
A, B
273Burkholderia ambifaria (strain ATCC BAA-244 / AMMD)N/A
Find proteins for Q0B2N4 (Burkholderia ambifaria (strain ATCC BAA-244 / AMMD))
Go to UniProtKB:  Q0B2N4
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download SDF File
Download CCD File
A, B
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
MSE
Query on MSE
A, B
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.77 Å
  • R-Value Free: 0.241
  • R-Value Work: 0.211
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 48.999α = 90.00
b = 70.956β = 90.00
c = 147.893γ = 90.00
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling
HKL-2000data collection
MOLREPphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2013-07-17
    Type: Initial release
