3VUZ

Crystal structure of histone methyltransferase SET7/9 in complex with AAM-1


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.5 Å
  • R-Value Free: 0.247
  • R-Value Work: 0.183

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Structures of histone methyltransferase SET7/9 in complexes with adenosylmethionine derivatives

Niwa, H.Handa, N.Tomabechi, Y.Honda, K.Toyama, M.Ohsawa, N.Shirouzu, M.Kagechika, H.Hirano, T.Umehara, T.Yokoyama, S.

(2013) Acta Crystallogr.,Sect.D 69: 595-602

  • DOI: 10.1107/S0907444912052092
  • Primary Citation of Related Structures:  3VV0

  • PubMed Abstract:
  • SET7/9 is a protein lysine methyltransferase that methylates histone H3 and nonhistone proteins such as p53, TAF10 and oestrogen receptor α. In previous work, novel inhibitors of SET7/9 that are amine analogues of the coenzyme S-(5'-adenosyl)-L-methi ...

    SET7/9 is a protein lysine methyltransferase that methylates histone H3 and nonhistone proteins such as p53, TAF10 and oestrogen receptor α. In previous work, novel inhibitors of SET7/9 that are amine analogues of the coenzyme S-(5'-adenosyl)-L-methionine (AdoMet) have been developed. Here, crystal structures of SET7/9 are reported in complexes with two AdoMet analogues, designated DAAM-3 and AAM-1, in which an n-hexylaminoethyl group or an n-hexyl group is attached to the N atom that replaces the S atom of AdoMet, respectively. In both structures, the inhibitors bind to the coenzyme-binding site and their additional alkyl chain binds in the lysine-access channel. The N atom in the azaalkyl chain of DAAM-3 is located at almost the same position as the N-methyl C atom of the methylated lysine side chain in the substrate-peptide complex structures and stabilizes complex formation by hydrogen bonding to the substrate-binding site residues of SET7/9. On the other hand, the alkyl chain of AAM-1, which is a weaker inhibitor than DAAM-3, binds in the lysine-access channel only through hydrophobic and van der Waals interactions. Unexpectedly, the substrate-binding site of SET7/9 complexed with AAM-1 specifically interacts with the artificial N-terminal sequence of an adjacent symmetry-related molecule, presumably stabilizing the alkyl chain of AAM-1.


    Organizational Affiliation

    RIKEN Systems and Structural Biology Center, Tsurumi, Yokohama, Japan.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Histone-lysine N-methyltransferase SETD7
A
263Homo sapiensGene Names: SETD7 (KIAA1717, KMT7, SET7, SET9)
EC: 2.1.1.43
Find proteins for Q8WTS6 (Homo sapiens)
Go to Gene View: SETD7
Go to UniProtKB:  Q8WTS6
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
K15
Query on K15

Download SDF File
Download CCD File
A
5'-{[(3S)-3-amino-3-carboxypropyl](hexyl)amino}-5'-deoxyadenosine
C20 H33 N7 O5
PUFLVFWUSGLSNL-BPAMBQHCSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.5 Å
  • R-Value Free: 0.247
  • R-Value Work: 0.183
  • Space Group: P 21 21 2
Unit Cell:
Length (Å)Angle (°)
a = 101.807α = 90.00
b = 39.223β = 90.00
c = 67.045γ = 90.00
Software Package:
Software NamePurpose
HKL-2000data reduction
HKL-2000data collection
PHENIXrefinement
PHASERphasing
HKL-2000data scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2013-03-27
    Type: Initial release
  • Version 1.1: 2014-04-30
    Type: Database references
  • Version 1.2: 2016-09-28
    Type: Structure summary
