3U7Z | pdb_00003u7z

Crystal structure of a putative metal binding protein RUMGNA_00854 (ZP_02040092.1) from Ruminococcus gnavus ATCC 29149 at 1.30 A resolution

PDB DOI: https://doi.org/10.2210/pdb3U7Z/pdb

Classification: METAL BINDING PROTEIN
Organism(s): Mediterraneibacter gnavus ATCC 29149
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2011-10-14 Released: 2011-11-02
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.30 Å
R-Value Free:
0.189 (Depositor), 0.194 (DCC)
R-Value Work:
0.138 (Depositor), 0.146 (DCC)
R-Value Observed:
0.140 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 3U7Z

This is version 1.5 of the entry. See complete history.

Literature

Crystal structure of a putative metal binding protein RUMGNA_00854 (ZP_02040092.1) from Ruminococcus gnavus ATCC 29149 at 1.30 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 23.13 kDa
Atom Count: 1,807
Modeled Residue Count: 193
Deposited Residue Count: 202
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
putative metal binding protein RUMGNA_00854	A, B	101	Mediterraneibacter gnavus ATCC 29149	Mutation(s): 0 Gene Names: RUMGNA_00854
UniProt
Find proteins for A7AZY1 (Mediterraneibacter gnavus (strain ATCC 29149 / DSM 114966 / JCM 6515 / VPI C7-9)) Explore A7AZY1 Go to UniProtKB: A7AZY1
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A7AZY1
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain V [auth B] SDF format, chain U [auth B] SDF format, chain T [auth B] SDF format, chain S [auth B] SDF format, chain R [auth B] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain V [auth B] MOL2 format, chain U [auth B] MOL2 format, chain T [auth B] MOL2 format, chain S [auth B] MOL2 format, chain R [auth B] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain V [auth B] mmCIF format, chain U [auth B] mmCIF format, chain T [auth B] mmCIF format, chain S [auth B] mmCIF format, chain R [auth B]	I [auth A] J [auth A] K [auth A] R [auth B] S [auth B] I [auth A], J [auth A], K [auth A], R [auth B], S [auth B], T [auth B], U [auth B], V [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B] Focus chain U [auth B] Focus chain V [auth B] Interactions & Density Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B] Focus chain U [auth B] Focus chain V [auth B]
CA Query on CA Download:Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain M [auth B] SDF format, chain O [auth B] SDF format, chain Q [auth B] SDF format, chain P [auth B] SDF format, chain N [auth B] SDF format, chain L [auth B] SDF format, chain H [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] SDF format, chain C [auth A] MOL2 format, chain G [auth A] MOL2 format, chain M [auth B] MOL2 format, chain O [auth B] MOL2 format, chain Q [auth B] MOL2 format, chain P [auth B] MOL2 format, chain N [auth B] MOL2 format, chain L [auth B] MOL2 format, chain H [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] mmCIF format, chain G [auth A] mmCIF format, chain M [auth B] mmCIF format, chain O [auth B] mmCIF format, chain Q [auth B] mmCIF format, chain P [auth B] mmCIF format, chain N [auth B] mmCIF format, chain L [auth B] mmCIF format, chain H [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A]	C [auth A] D [auth A] E [auth A] F [auth A] G [auth A] C [auth A], D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], L [auth B], M [auth B], N [auth B], O [auth B], P [auth B], Q [auth B]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.30 Å
R-Value Free: 0.189 (Depositor), 0.194 (DCC)
R-Value Work: 0.138 (Depositor), 0.146 (DCC)
R-Value Observed: 0.140 (Depositor)

Diffraction Data:

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 29.685	α = 73.13
b = 30.474	β = 83.79
c = 47.156	γ = 89.3

Software Package:

Software Name	Purpose
MolProbity	model building
PDB_EXTRACT	data extraction
MOLREP	phasing
SCALA	data scaling
REFMAC	refinement
MOSFLM	data reduction

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2011-11-02

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2011-11-02
Type: Initial release
Version 1.1: 2011-11-16
Changes: Structure summary
Version 1.2: 2017-11-08
Changes: Refinement description
Version 1.3: 2018-01-24
Changes: Database references
Version 1.4: 2023-02-01
Changes: Database references, Derived calculations
Version 1.5: 2023-09-20
Changes: Data collection, Refinement description
