3TNG | pdb_00003tng

The crystal structure of a possible phosphate acetyl/butaryl transferase from Listeria monocytogenes EGD-e.

• PDB DOI: https://doi.org/10.2210/pdb3TNG/pdb

• Classification: TRANSFERASE
• Organism(s): Listeria monocytogenes F6900
• Expression System: Escherichia coli BL21
• Mutation(s): No


• Deposited: 2011-09-01 Released: 2011-09-21
• Deposition Author(s): Tan, K., Zhou, M., Kwon, K., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.16 Å
• R-Value Free:
  0.242 (Depositor), 0.240 (DCC)
• R-Value Work:
  0.195 (Depositor), 0.195 (DCC)
• R-Value Observed:
  0.198 (Depositor)

Literature

The crystal structure of a possible phosphate acetyl/butaryl transferase from Listeria monocytogenes EGD-e.

Tan, K., Zhou, M., Kwon, K., Anderson, W.F., Joachimiak, A.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 31.92 kDa
• Atom Count: 2,238
• Modeled Residue Count: 287
• Deposited Residue Count: 291
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Lmo1369 protein	A	291	Listeria monocytogenes F6900	Mutation(s): 0  Gene Names: lmo1369
UniProt
Find proteins for Q8Y7B7 (Listeria monocytogenes serovar 1/2a (strain ATCC BAA-679 / EGD-e)) Explore Q8Y7B7  Go to UniProtKB:  Q8Y7B7

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PEG	D [auth A], E [auth A], F [auth A], G [auth A], H [auth A]	DI(HYDROXYETHYL)ETHER C4 H10 O3 MTHSVFCYNBDYFN-UHFFFAOYSA-N
NI	B [auth A], C [auth A]	NICKEL (II) ION Ni VEQPNABPJHWNSG-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.16 Å
• R-Value Free:  0.242 (Depositor), 0.240 (DCC)
• R-Value Work:  0.195 (Depositor), 0.195 (DCC)
• R-Value Observed: 0.198 (Depositor)

Diffraction Data: https://doi.org/10.18430/m33tng

Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 66.488	α = 90
b = 66.488	β = 90
c = 125.133	γ = 90

Software Package:

Software Name	Purpose
SBC-Collect	data collection
SHELXD	phasing
MLPHARE	phasing
DM	model building
ARP	model building
WARP	model building
HKL-3000	phasing
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
DM	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2011-09-21
Deposition Author(s): Tan, K., Zhou, M., Kwon, K., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

Revision History

• Version 1.0: 2011-09-21
  Type: Initial release

• Version 1.1: 2024-10-09
  Changes: Data collection, Database references, Derived calculations, Structure summary
