3TK6

factor Xa in complex with D46-5241

• PDB DOI: https://doi.org/10.2210/pdb3TK6/pdb

• Classification: HYDROLASE/HYDROLASE INHIBITOR
• Organism(s): Homo sapiens
• Mutation(s): No


• Deposited: 2011-08-25 Released: 2012-08-29
• Deposition Author(s): Suzuki, M., Mochizuki, A., Nagata, T., Takano, H., Kanno, H., Kishida, M., Ohta, T.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free: 0.241
• R-Value Work: 0.203
• R-Value Observed: 0.205

Literature

Zwitter ionic potent durable orally active Factor Xa inhibitor.

Mochizuki, A., Nagata, T., Takano, H., Kanno, H., Kishida, M., Suzuki, M., Ohta, T.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 2-mer - A1B1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 32.72 kDa
• Atom Count: 2,445
• Modelled Residue Count: 287
• Deposited Residue Count: 287
• Unique protein chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Factor X heavy chain	A	233	Homo sapiens	Mutation(s): 0  EC: 3.4.21.6
UniProt & NIH Common Fund Data Resources
Find proteins for P00742 (Homo sapiens) Explore P00742  Go to UniProtKB:  P00742
PHAROS:  P00742 GTEx:  ENSG00000126218

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Factor X light chain	B	54	Homo sapiens	Mutation(s): 0  EC: 3.4.21.6
UniProt & NIH Common Fund Data Resources
Find proteins for P00742 (Homo sapiens) Explore P00742  Go to UniProtKB:  P00742
PHAROS:  P00742 GTEx:  ENSG00000126218

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
D46	E [auth A]	N-[2-({[(5-chlorothiophen-2-yl)carbonyl]amino}methyl)phenyl]-5-methyl-4,5,6,7-tetrahydro[1,3]thiazolo[5,4-c]pyridine-2-carboxamide C20 H19 Cl N4 O2 S2 LMUFNFLXBDOGET-UHFFFAOYSA-N
CA	C [auth A], D [auth A]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N

Binding Affinity Annotations
ID	Source	Binding Affinity
D46	BindingDB:  3TK6	IC50: 1.7 (nM) from 1 assay(s)

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free: 0.241
• R-Value Work: 0.203
• R-Value Observed: 0.205
• Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 56.466	α = 90
b = 72.412	β = 90
c = 79.074	γ = 90

Software Package:

Software Name	Purpose
manufacturer	data collection
REFMAC	refinement
CrystalClear	data reduction
CrystalClear	data scaling
REFMAC	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2012-08-29
Deposition Author(s): Suzuki, M., Mochizuki, A., Nagata, T., Takano, H., Kanno, H., Kishida, M., Ohta, T.

Revision History

• Version 1.0: 2012-08-29
  Type: Initial release

• Version 1.1: 2017-11-08
  Changes: Refinement description
