3TE3

Coiled-coil oligomerization domain of the polycystin transient receptor potential channel PKD2L1


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.69 Å
  • R-Value Free: 0.290
  • R-Value Work: 0.253
  • R-Value Observed: 0.255

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Crystal structure and characterization of coiled-coil domain of the transient receptor potential channel PKD2L1.

Molland, K.L.Paul, L.N.Yernool, D.A.

(2011) Biochim Biophys Acta 1824: 413-421

  • DOI: 10.1016/j.bbapap.2011.12.002
  • Primary Citation of Related Structures:
    3TE3

  • PubMed Abstract:
  • The cation-permeable channel PKD2L1 forms a homomeric assembly as well as heteromeric associations with both PKD1 and PKD1L3, with the cytoplasmic regulatory domain (CRD) of PKD2L1 often playing a role in assembly and/or function. Our previous work indicated that the isolated PKD2L1 CRD assembles as a trimer in a manner dependent on the presence of a proposed oligomerization domain ...

    The cation-permeable channel PKD2L1 forms a homomeric assembly as well as heteromeric associations with both PKD1 and PKD1L3, with the cytoplasmic regulatory domain (CRD) of PKD2L1 often playing a role in assembly and/or function. Our previous work indicated that the isolated PKD2L1 CRD assembles as a trimer in a manner dependent on the presence of a proposed oligomerization domain. Herein we describe the 2.7Å crystal structure of a segment containing the PKD2L1 oligomerization domain which indicates that trimerization is driven by the β-branched residues at the first and fourth positions of a heptad repeat (commonly referred to as "a" and "d") and by a conserved R-h-x-x-h-E salt bridge motif that is largely unique to parallel trimeric coiled coils. Further analysis of the PKD2L1 CRD indicates that trimeric association is sufficiently strong that no other species are present in solution in an analytical ultracentrifugation experiment at the lowest measurable concentration of 750nM. Conversely, mutation of the "a" and "d" residues leads to formation of an exclusively monomeric species, independent of concentration. Although both monomeric and WT CRDs are stable in solution and bind calcium with 0.9μM affinity, circular dichroism studies reveal that the monomer loses 25% more α-helical content than WT when stripped of this ligand, suggesting that the CRD structure is stabilized by trimerization in the ligand-free state. This stability could play a role in the function of the full-length complex, indicating that trimerization may be important for both homo- and possibly heteromeric assemblies of PKD2L1.


    Organizational Affiliation

    Department of Biological Sciences, Purdue University, West Lafayette, IN 47907, USA. kmolland@purdue.edu



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Polycystic kidney disease 2-like 1 proteinA, B, C, D, E, F39Homo sapiensMutation(s): 0
Gene Names: PKD2L1PKD2LPKDLTRPP3
UniProt & NIH Common Fund Data Resources
Find proteins for Q9P0L9 (Homo sapiens)
Explore Q9P0L9
Go to UniProtKB:  Q9P0L9
PHAROS:  Q9P0L9
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.69 Å
  • R-Value Free: 0.290
  • R-Value Work: 0.253
  • R-Value Observed: 0.255
  • Space Group: P 65 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 74.634α = 90
b = 74.634β = 90
c = 185.791γ = 120
Software Package:
Software NamePurpose
MAR345data collection
PHASERphasing
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report




Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2012-01-18
    Type: Initial release
  • Version 1.1: 2012-02-08
    Changes: Database references
  • Version 1.2: 2017-11-08
    Changes: Refinement description, Structure summary
