3TAK | pdb_00003tak

Crystal structure of the complex of DHDPS from Acinetobacter baumannii with Pyruvate at 1.4 A resolution

• PDB DOI: https://doi.org/10.2210/pdb3TAK/pdb

• Classification: LYASE
• Organism(s): Acinetobacter baumannii ATCC 19606 = CIP 70.34 = JCM 6841
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2011-08-04 Released: 2011-08-24
• Deposition Author(s): Singh, A., Kaushik, S., Sinha, M., Tewari, R., Kaur, P., Sharma, S., Singh, T.P.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.42 Å
• R-Value Free:
  0.188 (Depositor), 0.190 (DCC)
• R-Value Work:
  0.164 (Depositor), 0.160 (DCC)
• R-Value Observed:
  0.165 (Depositor)

Starting Model: experimental

Literature

Crystal structure of the complex of DHDPS from Acinetobacter baumannii with Pyruvate at 1.4 A resolution

Singh, A., Kaushik, S., Sinha, M., Tewari, R., Kaur, P., Sharma, S., Singh, T.P.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 63.3 kDa
• Atom Count: 5,091
• Modeled Residue Count: 582
• Deposited Residue Count: 582
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Dihydrodipicolinate synthase	A, B	291	Acinetobacter baumannii ATCC 19606 = CIP 70.34 = JCM 6841	Mutation(s): 0  Gene Names: dhdps, HMPREF0010_03414 EC: 4.2.1.52 (PDB Primary Data), 4.3.3.7 (UniProt)
UniProt
Find proteins for D0CFC3 (Acinetobacter baumannii (strain ATCC 19606 / DSM 30007 / JCM 6841 / CCUG 19606 / CIP 70.34 / NBRC 109757 / NCIMB 12457 / NCTC 12156 / 81)) Explore D0CFC3  Go to UniProtKB:  D0CFC3

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PEG	J [auth B]	DI(HYDROXYETHYL)ETHER C4 H10 O3 MTHSVFCYNBDYFN-UHFFFAOYSA-N
GOL	C [auth A], D [auth A], F [auth B], G [auth B], H [auth B]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N
PYR	E [auth A], I [auth B]	PYRUVIC ACID C3 H4 O3 LCTONWCANYUPML-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.42 Å
• R-Value Free:  0.188 (Depositor), 0.190 (DCC)
• R-Value Work:  0.164 (Depositor), 0.160 (DCC)
• R-Value Observed: 0.165 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 51.25	α = 90
b = 122.42	β = 116.01
c = 52.31	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data collection
AMoRE	phasing
REFMAC	refinement
DENZO	data reduction
SCALEPACK	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2011-08-24
Deposition Author(s): Singh, A., Kaushik, S., Sinha, M., Tewari, R., Kaur, P., Sharma, S., Singh, T.P.

Revision History

• Version 1.0: 2011-08-24
  Type: Initial release

• Version 1.1: 2023-11-01
  Changes: Data collection, Database references, Derived calculations, Refinement description
• Version 2.0: 2023-11-15
  Changes: Atomic model, Data collection, Derived calculations
• Version 2.1: 2024-10-16
  Changes: Structure summary
