3T7G

Atg8 transfer from Atg7 to Atg3: a distinctive E1-E2 architecture and mechanism in the autophagy pathway


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.08 Å
  • R-Value Free: 0.206
  • R-Value Work: 0.182

wwPDB Validation 3D Report Full Report


This is version 1.0 of the entry. See complete history

Literature

Atg8 transfer from atg7 to atg3: a distinctive e1-e2 architecture and mechanism in the autophagy pathway.

Taherbhoy, A.M.Tait, S.W.Kaiser, S.E.Williams, A.H.Deng, A.Nourse, A.Hammel, M.Kurinov, I.Rock, C.O.Green, D.R.Schulman, B.A.

(2011) Mol.Cell 44: 451-461

  • DOI: 10.1016/j.molcel.2011.08.034
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Atg7 is a noncanonical, homodimeric E1 enzyme that interacts with the noncanonical E2 enzyme, Atg3, to mediate conjugation of the ubiquitin-like protein (UBL) Atg8 during autophagy. Here we report that the unique N-terminal domain of Atg7 (Atg7(NTD)) ...

    Atg7 is a noncanonical, homodimeric E1 enzyme that interacts with the noncanonical E2 enzyme, Atg3, to mediate conjugation of the ubiquitin-like protein (UBL) Atg8 during autophagy. Here we report that the unique N-terminal domain of Atg7 (Atg7(NTD)) recruits a unique "flexible region" from Atg3 (Atg3(FR)). The structure of an Atg7(NTD)-Atg3(FR) complex reveals hydrophobic residues from Atg3 engaging a conserved groove in Atg7, important for Atg8 conjugation. We also report the structure of the homodimeric Atg7 C-terminal domain, which is homologous to canonical E1s and bacterial antecedents. The structures, SAXS, and crosslinking data allow modeling of a full-length, dimeric (Atg7~Atg8-Atg3)(2) complex. The model and biochemical data provide a rationale for Atg7 dimerization: Atg8 is transferred in trans from the catalytic cysteine of one Atg7 protomer to Atg3 bound to the N-terminal domain of the opposite Atg7 protomer within the homodimer. The studies reveal a distinctive E1~UBL-E2 architecture for enzymes mediating autophagy.


    Organizational Affiliation

    Department of Structural Biology, St. Jude Children's Research Hospital, Memphis, TN 38105, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Ubiquitin-like modifier-activating enzyme ATG7
A, B
291Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: ATG7 (APG7, CVT2)
Find proteins for P38862 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: ATG7
Go to UniProtKB:  P38862
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Autophagy-related protein 3
D, C
17Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: ATG3 (APG3, AUT1)
Find proteins for P40344 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: ATG3
Go to UniProtKB:  P40344
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.08 Å
  • R-Value Free: 0.206
  • R-Value Work: 0.182
  • Space Group: C 1 2 1
Unit Cell:
Length (Å)Angle (°)
a = 152.135α = 90.00
b = 99.429β = 113.13
c = 71.502γ = 90.00
Software Package:
Software NamePurpose
HKL-2000data reduction
PHENIXphasing
HKL-2000data scaling
PHENIXmodel building
PHENIXrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2011-11-23
    Type: Initial release
