3SY3 | pdb_00003sy3

GBAA_1210 protein, a putative adenylate cyclase, from Bacillus anthracis

• PDB DOI: https://doi.org/10.2210/pdb3SY3/pdb

• Classification: LYASE
• Organism(s): Bacillus anthracis str. 'Ames Ancestor
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2011-07-15 Released: 2011-07-27
• Deposition Author(s): Osipiuk, J., Gu, M., Kwon, K., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.14 Å
• R-Value Free:
  0.248 (Depositor), 0.247 (DCC)
• R-Value Work:
  0.196 (Depositor), 0.196 (DCC)
• R-Value Observed:
  0.199 (Depositor)

Literature

GBAA_1210 protein, a putative adenylate cyclase, from Bacillus anthracis.

Osipiuk, J., Gu, M., Kwon, K., Anderson, W.F., Joachimiak, A.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 91.76 kDa
• Atom Count: 5,947
• Modeled Residue Count: 704
• Deposited Residue Count: 780
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
GBAA_1210 protein	A, B, C, D	195	Bacillus anthracis str. 'Ames Ancestor	Mutation(s): 1  Gene Names: BAS1117, BA_1210, GBAA_1210
UniProt
Find proteins for A0A6L8P3N5 (Bacillus anthracis) Explore A0A6L8P3N5  Go to UniProtKB:  A0A6L8P3N5

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PO4	E [auth A], F [auth A], G [auth B], H [auth B], I [auth C], J [auth C], K [auth C], L [auth D], M [auth D], N [auth D]	PHOSPHATE ION O4 P NBIIXXVUZAFLBC-UHFFFAOYSA-K

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B, C, D	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.14 Å
• R-Value Free:  0.248 (Depositor), 0.247 (DCC)
• R-Value Work:  0.196 (Depositor), 0.196 (DCC)
• R-Value Observed: 0.199 (Depositor)

Diffraction Data: https://doi.org/10.18430/m33sy3

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 67.322	α = 90
b = 85.997	β = 102.12
c = 76.513	γ = 90

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
REFMAC	refinement
PDB_EXTRACT	data extraction
SBC-Collect	data collection
HKL-3000	data reduction
HKL-3000	data scaling
PHENIX	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2011-07-27
Deposition Author(s): Osipiuk, J., Gu, M., Kwon, K., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

Revision History

• Version 1.0: 2011-07-27
  Type: Initial release

• Version 1.1: 2017-11-08
  Changes: Refinement description
• Version 1.2: 2024-11-20
  Changes: Data collection, Database references, Derived calculations, Structure summary
