3SB3 | pdb_00003sb3

Crystal structure of an apag protein (PA1934) from pseudomonas aeruginosa pao1 at 1.83 A resolution

• PDB DOI: https://doi.org/10.2210/pdb3SB3/pdb

• Classification: Structural Genomics, Unknown Function
• Organism(s): Pseudomonas aeruginosa
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2011-06-03 Released: 2011-06-29
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.83 Å
• R-Value Free:
  0.223 (Depositor), 0.230 (DCC)
• R-Value Work:
  0.187 (Depositor), 0.190 (DCC)
• R-Value Observed:
  0.189 (Depositor)

Literature

Crystal structure of an ApaG protein (PA1934) from PSEUDOMONAS AERUGINOSA at 1.83 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C4  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 11.29 kDa
• Atom Count: 846
• Modeled Residue Count: 101
• Deposited Residue Count: 106
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
ApaG protein	A	106	Pseudomonas aeruginosa	Mutation(s): 0  Gene Names: PA1934
UniProt
Find proteins for Q9I2H0 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1)) Explore Q9I2H0  Go to UniProtKB:  Q9I2H0

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PO4	B [auth A]	PHOSPHATE ION O4 P NBIIXXVUZAFLBC-UHFFFAOYSA-K

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.83 Å
• R-Value Free:  0.223 (Depositor), 0.230 (DCC)
• R-Value Work:  0.187 (Depositor), 0.190 (DCC)
• R-Value Observed: 0.189 (Depositor)

Diffraction Data: https://doi.org/10.18430/M33SB3

Space Group: P 4 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 66.08	α = 90
b = 66.08	β = 90
c = 50.538	γ = 90

Software Package:

Software Name	Purpose
MolProbity	model building
PDB_EXTRACT	data extraction
SHELX	phasing
SHARP	phasing
XSCALE	data scaling
REFMAC	refinement
XDS	data reduction
SHELXD	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2011-06-29
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2011-06-29
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 1.2: 2011-11-16
  Changes: Structure summary
• Version 1.3: 2017-10-25
  Changes: Author supporting evidence, Refinement description
• Version 1.4: 2018-01-24
  Changes: Database references
• Version 1.5: 2023-02-01
  Changes: Database references, Derived calculations
• Version 1.6: 2024-11-20
  Changes: Data collection, Structure summary
