3QWL | pdb_00003qwl

Crystal structure of human TBC1 domain family member 7

• PDB DOI: https://doi.org/10.2210/pdb3QWL/pdb

• Classification: HYDROLASE ACTIVATOR
• Organism(s): Homo sapiens
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2011-02-28 Released: 2011-06-01
• Deposition Author(s): Guan, X., Tempel, W., Tong, Y., Wernimont, A.K., Landry, R., Arrowsmith, C.H., Edwards, A.M., Bountra, C., Weigelt, J., Park, H., Structural Genomics Consortium (SGC)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.90 Å
• R-Value Free:
  0.259 (Depositor), 0.250 (DCC)
• R-Value Work:
  0.211 (Depositor), 0.210 (DCC)
• R-Value Observed:
  0.213 (Depositor)

Literature

Crystal structure of human TBC1 domain family member 7

Guan, X., Tempel, W., Tong, Y., Wernimont, A.K., Landry, R., Arrowsmith, C.H., Edwards, A.M., Bountra, C., Weigelt, J., Park, H.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 34.08 kDa
• Atom Count: 2,195
• Modeled Residue Count: 272
• Deposited Residue Count: 294
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
TBC1 domain family member 7	A	294	Homo sapiens	Mutation(s): 0  Gene Names: TBC1D7, HSPC239, TBC7
UniProt & NIH Common Fund Data Resources
Find proteins for Q9P0N9 (Homo sapiens) Explore Q9P0N9  Go to UniProtKB:  Q9P0N9
PHAROS:  Q9P0N9 GTEx:  ENSG00000145979

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
UNX	B [auth A], C [auth A], D [auth A], E [auth A]	UNKNOWN ATOM OR ION X

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.90 Å
• R-Value Free:  0.259 (Depositor), 0.250 (DCC)
• R-Value Work:  0.211 (Depositor), 0.210 (DCC)
• R-Value Observed: 0.213 (Depositor)

Diffraction Data: https://doi.org/10.18430/M33QWL

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 34.574	α = 90
b = 83.984	β = 90
c = 87.684	γ = 90

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
SHARP	phasing
DM	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction
HKL-3000	data reduction
HKL-3000	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2011-06-01
Deposition Author(s): Guan, X., Tempel, W., Tong, Y., Wernimont, A.K., Landry, R., Arrowsmith, C.H., Edwards, A.M., Bountra, C., Weigelt, J., Park, H., Structural Genomics Consortium (SGC)

Revision History

• Version 1.0: 2011-06-01
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 1.2: 2017-11-08
  Changes: Refinement description
• Version 1.3: 2024-02-21
  Changes: Data collection, Database references
