3QWE

Crystal structure of the N-terminal domain of the GEM interacting protein

PDB DOI: https://doi.org/10.2210/pdb3QWE/pdb

Classification: PROTEIN BINDING
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21
Mutation(s): No

Deposited: 2011-02-28 Released: 2011-03-23
Deposition Author(s): Guan, X., Tempel, W., Tong, Y., Shen, L., Wang, H., Wernimont, A.K., Arrowsmith, C.H., Edwards, A.M., Bountra, C., Weigelt, J., Park, H., Structural Genomics Consortium (SGC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.40 Å
R-Value Free: 0.231
R-Value Work: 0.227
R-Value Observed: 0.227

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

Crystal structure of the N-terminal domain of the GEM interacting protein

Guan, X., Tempel, W., Tong, Y., Shen, L., Wang, H., Wernimont, A.K., Arrowsmith, C.H., Edwards, A.M., Bountra, C., Weigelt, J., Park, H.

To be published.

Macromolecule Content

Total Structure Weight: 32.18 kDa
Atom Count: 2,047
Modelled Residue Count: 260
Deposited Residue Count: 279
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
GEM-interacting protein	A	279	Homo sapiens	Mutation(s): 0 Gene Names: GMIP
UniProt & NIH Common Fund Data Resources
Find proteins for Q9P107 (Homo sapiens) Explore Q9P107 Go to UniProtKB: Q9P107
PHAROS: Q9P107 GTEx: ENSG00000089639
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q9P107
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
UNX Query on UNX Download Ideal Coordinates CCD File SDF format, chain B [auth A] SDF format, chain BA [auth A] SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain DA [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain M [auth A] SDF format, chain N [auth A] SDF format, chain Q [auth A] SDF format, chain R [auth A] SDF format, chain S [auth A] SDF format, chain T [auth A] SDF format, chain U [auth A] SDF format, chain V [auth A] SDF format, chain W [auth A] SDF format, chain Y [auth A] SDF format, chain Z [auth A] SDF format, chain AA [auth A] SDF format, chain CA [auth A] SDF format, chain E [auth A] SDF format, chain O [auth A] SDF format, chain P [auth A] SDF format, chain X [auth A] MOL2 format, chain B [auth A] MOL2 format, chain BA [auth A] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain DA [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] MOL2 format, chain N [auth A] MOL2 format, chain Q [auth A] MOL2 format, chain R [auth A] MOL2 format, chain S [auth A] MOL2 format, chain T [auth A] MOL2 format, chain U [auth A] MOL2 format, chain V [auth A] MOL2 format, chain W [auth A] MOL2 format, chain Y [auth A] MOL2 format, chain Z [auth A] MOL2 format, chain AA [auth A] MOL2 format, chain CA [auth A] MOL2 format, chain E [auth A] MOL2 format, chain O [auth A] MOL2 format, chain P [auth A] MOL2 format, chain X [auth A]	AA [auth A] B [auth A] BA [auth A] C [auth A] CA [auth A] AA [auth A], B [auth A], BA [auth A], C [auth A], CA [auth A], D [auth A], DA [auth A], E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], K [auth A], L [auth A], M [auth A], N [auth A], O [auth A], P [auth A], Q [auth A], R [auth A], S [auth A], T [auth A], U [auth A], V [auth A], W [auth A], X [auth A], Y [auth A], Z [auth A]	UNKNOWN ATOM OR ION X		Interactions Focus chain AA [auth A] Focus chain B [auth A] Focus chain BA [auth A] Focus chain C [auth A] Focus chain CA [auth A] Focus chain D [auth A] Focus chain DA [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A] Focus chain R [auth A] Focus chain S [auth A] Focus chain T [auth A] Focus chain U [auth A] Focus chain V [auth A] Focus chain W [auth A] Focus chain X [auth A] Focus chain Y [auth A] Focus chain Z [auth A] Interactions & Density Focus chain AA [auth A] Focus chain B [auth A] Focus chain BA [auth A] Focus chain C [auth A] Focus chain CA [auth A] Focus chain D [auth A] Focus chain DA [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A] Focus chain R [auth A] Focus chain S [auth A] Focus chain T [auth A] Focus chain U [auth A] Focus chain V [auth A] Focus chain W [auth A] Focus chain X [auth A] Focus chain Y [auth A] Focus chain Z [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.40 Å
R-Value Free: 0.231
R-Value Work: 0.227
R-Value Observed: 0.227
Space Group: P 6₅ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 57.53	α = 90
b = 57.53	β = 90
c = 500.73	γ = 120

Software Package:

Software Name	Purpose
XSCALE	data processing
BUSTER-TNT	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
DENZO	data reduction
XSCALE	data scaling
SCALEPACK	data scaling
SHELXDE	phasing
BUSTER	refinement
