3QET

RB69 DNA Polymerase (L561A/S565G/Y567A) Ternary Complex with dTTP Opposite dT


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.08 Å
  • R-Value Free: 0.217
  • R-Value Work: 0.182

wwPDB Validation 3D Report Full Report


This is version 1.0 of the entry. See complete history

Literature

Hydrogen-Bonding Capability of Difluorotoluene Nucleoside in Replication Complexes

Xia, S.Konigsberg, W.H.Wang, J.

To be published.

Macromolecules

Find similar proteins by: Sequence  |  Structure


Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
DNA polymerase
A
903Enterobacteria phage RB69Mutation(s): 5
Gene Names: 43
EC: 2.7.7.7, 3.1.11.-
Find proteins for Q38087 (Enterobacteria phage RB69)
Go to UniProtKB:  Q38087
Entity ID: 2
MoleculeChainsLengthOrganism
DNA (5'-D(*TP*CP*AP*TP*GP*TP*AP*AP*GP*CP*AP*GP*TP*CP*CP*GP*CP*G)-3')T18N/A
Entity ID: 3
MoleculeChainsLengthOrganism
DNA (5'-D(*GP*CP*GP*GP*AP*CP*TP*GP*CP*TP*TP*AP*(DOC))-3')P13N/A
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
CA
Query on CA

Download SDF File
Download CCD File
A
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
 Ligand Interaction
TTP
Query on TTP

Download SDF File
Download CCD File
A
THYMIDINE-5'-TRIPHOSPHATE
C10 H17 N2 O14 P3
NHVNXKFIZYSCEB-XLPZGREQSA-N
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
DOC
Query on DOC
P
DNA LINKINGC9 H14 N3 O6 PDC
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.08 Å
  • R-Value Free: 0.217
  • R-Value Work: 0.182
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 78.381α = 90.00
b = 118.508β = 90.00
c = 130.117γ = 90.00
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
HKL-2000data collection
HKL-2000data scaling
AMoREphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2012-01-25
    Type: Initial release
