3QBF | pdb_00003qbf

HIV-1 protease (mutant Q7K L33I L63I) in complex with a three-armed pyrrolidine-based inhibitor

• PDB DOI: https://doi.org/10.2210/pdb3QBF/pdb

• Classification: HYDROLASE/HYDROLASE INHIBITOR
• Organism(s): Human immunodeficiency virus type 1 (BRU ISOLATE)
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2011-01-13 Released: 2012-01-18
• Deposition Author(s): Lindemann, I., Heine, A., Klebe, G.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.45 Å
• R-Value Free:
  0.199 (Depositor), 0.190 (DCC)
• R-Value Work:
  0.177 (Depositor), 0.170 (DCC)
• R-Value Observed:
  0.179 (Depositor)

Starting Model: experimental

Literature

Design of a series of novel three-armed pyrrolidine-based inhibitors for HIV-1 protease

Lindemann, I., Klee, N., Heine, A., Diederich, W.E., Klebe, G.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 22.55 kDa
• Atom Count: 1,895
• Modeled Residue Count: 198
• Deposited Residue Count: 198
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Protease	A, B	99	Human immunodeficiency virus type 1 (BRU ISOLATE)	Mutation(s): 3  EC: 3.4.23.16
UniProt
Find proteins for P03367 (Human immunodeficiency virus type 1 group M subtype B (isolate BRU/LAI)) Explore P03367  Go to UniProtKB:  P03367

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
JHG	C [auth A]	4-{(3-phenylpropyl)[(3S,4S)-4-{[4-(trifluoromethyl)benzyl]amino}pyrrolidin-3-yl]sulfamoyl}benzamide C28 H31 F3 N4 O3 S PREONNALBCMUBU-UIOOFZCWSA-N
GOL	D [auth A], F [auth B], G [auth B]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N
CL	E [auth A], H [auth B], I [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.45 Å
• R-Value Free:  0.199 (Depositor), 0.190 (DCC)
• R-Value Work:  0.177 (Depositor), 0.170 (DCC)
• R-Value Observed: 0.179 (Depositor)

Space Group: P 2₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 58.2	α = 90
b = 86.14	β = 90
c = 46.49	γ = 90

Software Package:

Software Name	Purpose
MAR345dtb	data collection
PHASER	phasing
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2012-01-18
Deposition Author(s): Lindemann, I., Heine, A., Klebe, G.

Revision History

• Version 1.0: 2012-01-18
  Type: Initial release

• Version 1.1: 2023-11-01
  Changes: Data collection, Database references, Derived calculations, Refinement description
