3Q0K | pdb_00003q0k

Crystal structure of Human PACSIN 2 F-BAR

PDB DOI: https://doi.org/10.2210/pdb3Q0K/pdb

Classification: ENDOCYTOSIS
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No
Membrane Protein: Yes OPM

Deposited: 2010-12-15 Released: 2012-02-15
Deposition Author(s): Bai, X., Meng, G., Zheng, X.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.60 Å
R-Value Free:
0.292 (Depositor), 0.241 (DCC)
R-Value Work:
0.201 (Depositor), 0.204 (DCC)
R-Value Observed:
0.206 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 3Q0K

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of human PACSIN 2 F-BAR domain

Bai, X., Meng, G., Zheng, X.

To be published.

Macromolecule Content

Total Structure Weight: 137.32 kDa
Atom Count: 9,729
Modeled Residue Count: 1,150
Deposited Residue Count: 1,156
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Protein kinase C and casein kinase substrate in neurons protein 2	A, B, C, D	289	Homo sapiens	Mutation(s): 0 Gene Names: PACSIN2 Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for Q9UNF0 (Homo sapiens) Explore Q9UNF0 Go to UniProtKB: Q9UNF0
PHAROS: Q9UNF0 GTEx: ENSG00000100266
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9UNF0
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CA Query on CA Download:Ideal Coordinates CCD File SDF format, chain H [auth D] SDF format, chain G [auth C] SDF format, chain F [auth B] SDF format, chain E [auth A] MOL2 format, chain H [auth D] MOL2 format, chain G [auth C] MOL2 format, chain F [auth B] MOL2 format, chain E [auth A] mmCIF format, chain H [auth D] mmCIF format, chain G [auth C] mmCIF format, chain F [auth B] mmCIF format, chain E [auth A]	E [auth A], F [auth B], G [auth C], H [auth D]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth B] Focus chain G [auth C] Focus chain H [auth D] Interactions & Density Focus chain E [auth A] Focus chain F [auth B] Focus chain G [auth C] Focus chain H [auth D]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.60 Å
R-Value Free: 0.292 (Depositor), 0.241 (DCC)
R-Value Work: 0.201 (Depositor), 0.204 (DCC)
R-Value Observed: 0.206 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 31.562	α = 90
b = 353.588	β = 90.02
c = 86.045	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data collection
AMoRE	phasing
REFMAC	refinement
MOSFLM	data reduction
SCALA	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2012-02-15

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2012-02-15
Type: Initial release
Version 1.1: 2023-11-01
Changes: Data collection, Database references, Derived calculations, Refinement description
