3PES | pdb_00003pes

Crystal structure of uncharacterized protein from Pseudomonas phage YuA

PDB DOI: https://doi.org/10.2210/pdb3PES/pdb

Classification: Structural genomics, Unknown function
Organism(s): Pseudomonas virus Yua
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2010-10-27 Released: 2010-12-08
Deposition Author(s): Nocek, B., Stein, A., Evdokimove, A., Egorova, O., Savchenko, A., Edwards, A., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.30 Å
R-Value Free:
0.205 (Depositor), 0.204 (DCC)
R-Value Work:
0.176 (Depositor), 0.176 (DCC)
R-Value Observed:
0.177 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3PES

This is version 1.2 of the entry. See complete history.

Literature

Crystal structure of uncharacterized protein from Pseudomonas phage YuA

Nocek, B., Stein, A., Evdokimove, A., Egorova, O., Savchenko, A., Edwards, A., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 19.76 kDa
Atom Count: 1,648
Modeled Residue Count: 165
Deposited Residue Count: 170
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Uncharacterized protein gp49	A, B	85	Pseudomonas virus Yua	Mutation(s): 0 Gene Names: gp49
UniProt
Find proteins for A9J573 (Pseudomonas phage YuA) Explore A9J573 Go to UniProtKB: A9J573
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A9J573
Sequence Annotations Expand
Reference Sequence

Small Molecules

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.30 Å
R-Value Free: 0.205 (Depositor), 0.204 (DCC)
R-Value Work: 0.176 (Depositor), 0.176 (DCC)
R-Value Observed: 0.177 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 38.059	α = 90
b = 59.745	β = 103.98
c = 38.154	γ = 90

Software Package:

Software Name	Purpose
SBC-Collect	data collection
HKL-3000	phasing
SHELX	model building
ARP/wARP	model building
REFMAC	refinement
HKL-3000	data reduction
HKL-3000	data scaling
SHELX	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2010-12-08

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2010-12-08
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2024-11-20
Changes: Data collection, Database references, Derived calculations, Structure summary
