3OZY | pdb_00003ozy

Crystal structure of enolase superfamily member from Bordetella bronchiseptica complexed with Mg and m-Xylarate

PDB DOI: https://doi.org/10.2210/pdb3OZY/pdb

Classification: UNKNOWN FUNCTION
Organism(s): Bordetella bronchiseptica
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2010-09-27 Released: 2011-09-28
Deposition Author(s): Fedorov, A.A., Fedorov, E.V., Wichelecki, D., Gerlt, J.A., Almo, S.C.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.30 Å
R-Value Free:
0.172 (Depositor), 0.167 (DCC)
R-Value Work:
0.154 (Depositor), 0.150 (DCC)
R-Value Observed:
0.155 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of enolase superfamily member from Bordetella bronchiseptica complexed with Mg and m-Xylarate

Fedorov, A.A., Fedorov, E.V., Wichelecki, D., Gerlt, J.A., Almo, S.C.

To be published.

Macromolecule Content

Total Structure Weight: 85.9 kDa
Atom Count: 7,148
Modeled Residue Count: 772
Deposited Residue Count: 778
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative mandelate racemase	A, B	389	Bordetella bronchiseptica	Mutation(s): 0 Gene Names: BB4687
UniProt
Find proteins for A0A0H3LT39 (Bordetella bronchiseptica (strain ATCC BAA-588 / NCTC 13252 / RB50)) Explore A0A0H3LT39 Go to UniProtKB: A0A0H3LT39
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A0H3LT39
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
DXL Query on DXL Download:Ideal Coordinates CCD File SDF format, chain L [auth B] MOL2 format, chain L [auth B] mmCIF format, chain L [auth B]	L [auth B]	D-xylaric acid C₅ H₈ O₇ NPTTZSYLTYJCPR-FFEAPLRNSA-N		Interactions Focus chain L [auth B] Interactions & Density Focus chain L [auth B]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain N [auth B] SDF format, chain M [auth B] SDF format, chain F [auth A] SDF format, chain E [auth A] MOL2 format, chain N [auth B] MOL2 format, chain M [auth B] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] mmCIF format, chain N [auth B] mmCIF format, chain M [auth B] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A]	E [auth A], F [auth A], M [auth B], N [auth B]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain M [auth B] Focus chain N [auth B] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain M [auth B] Focus chain N [auth B]
ACY Query on ACY Download:Ideal Coordinates CCD File SDF format, chain Q [auth B] SDF format, chain P [auth B] SDF format, chain O [auth B] SDF format, chain I [auth A] SDF format, chain H [auth A] SDF format, chain G [auth A] MOL2 format, chain Q [auth B] MOL2 format, chain P [auth B] MOL2 format, chain O [auth B] MOL2 format, chain I [auth A] MOL2 format, chain H [auth A] MOL2 format, chain G [auth A] mmCIF format, chain Q [auth B] mmCIF format, chain P [auth B] mmCIF format, chain O [auth B] mmCIF format, chain I [auth A] mmCIF format, chain H [auth A] mmCIF format, chain G [auth A]	G [auth A] H [auth A] I [auth A] O [auth B] P [auth B] G [auth A], H [auth A], I [auth A], O [auth B], P [auth B], Q [auth B]	ACETIC ACID C₂ H₄ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Interactions & Density Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain K [auth B] SDF format, chain J [auth B] SDF format, chain D [auth A] SDF format, chain C [auth A] MOL2 format, chain K [auth B] MOL2 format, chain J [auth B] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] mmCIF format, chain K [auth B] mmCIF format, chain J [auth B] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A]	C [auth A], D [auth A], J [auth B], K [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain J [auth B] Focus chain K [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain J [auth B] Focus chain K [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.30 Å
R-Value Free: 0.172 (Depositor), 0.167 (DCC)
R-Value Work: 0.154 (Depositor), 0.150 (DCC)
R-Value Observed: 0.155 (Depositor)

Space Group: I 4

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 116.769	α = 90
b = 116.769	β = 90
c = 128.417	γ = 90

Software Package:

Software Name	Purpose
ADSC	data collection
BALBES	phasing
PHENIX	refinement
DENZO	data reduction
SCALEPACK	data scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2011-09-28

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2011-09-28
Type: Initial release
Version 1.1: 2023-09-06
Changes: Data collection, Database references, Derived calculations, Refinement description
