3OTM | pdb_00003otm

Crystal structures of wild-type gamma-carbonic anhydrase from Methanosarcina thermophila

• PDB DOI: https://doi.org/10.2210/pdb3OTM/pdb

• Classification: LYASE
• Organism(s): Methanosarcina thermophila
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2010-09-13 Released: 2011-10-26
• Deposition Author(s): Domsic, J.F., Robbins, A.H., McKenna, R.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.50 Å
• R-Value Free:
  0.156 (Depositor), 0.150 (DCC)
• R-Value Work:
  0.136 (Depositor), 0.130 (DCC)
• R-Value Observed:
  0.137 (Depositor)

Literature

Crystal structures of gamma-carbonic anhydrase mutants from Methanosarcina thermophila

Domsic, J.F., Robbins, A.H., McKenna, R.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C3  (Explore in 3D)
Global Stoichiometry: Homo 3-mer - A3

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 22.83 kDa
• Atom Count: 1,700
• Modeled Residue Count: 205
• Deposited Residue Count: 212
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Carbonic anhydrase	A	212	Methanosarcina thermophila	Mutation(s): 0  EC: 4.2.1.1
UniProt
Find proteins for P40881 (Methanosarcina thermophila (strain ATCC 43570 / DSM 1825 / OCM 12 / VKM B-1830 / TM-1)) Explore P40881  Go to UniProtKB:  P40881

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ZN	B [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.50 Å
• R-Value Free:  0.156 (Depositor), 0.150 (DCC)
• R-Value Work:  0.136 (Depositor), 0.130 (DCC)
• R-Value Observed: 0.137 (Depositor)

Space Group: P 2₁ 3

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 83.521	α = 90
b = 83.521	β = 90
c = 83.521	γ = 90

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
CrystalClear	data collection
HKL-2000	data reduction
CNS	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2011-10-26
Deposition Author(s): Domsic, J.F., Robbins, A.H., McKenna, R.

Revision History

• Version 1.0: 2011-10-26
  Type: Initial release

• Version 1.1: 2011-11-16
  Changes: Structure summary
• Version 1.2: 2017-11-08
  Changes: Refinement description
• Version 1.3: 2024-02-21
  Changes: Data collection, Database references, Derived calculations
