3OIZ | pdb_00003oiz

Crystal structure of antisigma-factor antagonist, STAS domain from Rhodobacter sphaeroides

PDB DOI: https://doi.org/10.2210/pdb3OIZ/pdb

Classification: MEMBRANE PROTEIN
Organism(s): Cereibacter sphaeroides 2.4.1
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No
Membrane Protein: Yes OPM

Deposited: 2010-08-20 Released: 2010-09-08
Deposition Author(s): Chang, C., Marshall, N., Freeman, L., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.65 Å
R-Value Free:
0.216 (Depositor), 0.209 (DCC)
R-Value Work:
0.160 (Depositor), 0.168 (DCC)
R-Value Observed:
0.162 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

Crystal structure of antisigma-factor antagonist, STAS domain from Rhodobacter sphaeroides

Chang, C., Marshall, N., Freeman, L., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 11.44 kDa
Atom Count: 900
Modeled Residue Count: 92
Deposited Residue Count: 99
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Antisigma-factor antagonist, STAS	A	99	Cereibacter sphaeroides 2.4.1	Mutation(s): 0 Gene Names: RHOS4_40800, RSP_4197 Membrane Entity: Yes
UniProt
Find proteins for Q3IUY6 (Cereibacter sphaeroides (strain ATCC 17023 / DSM 158 / JCM 6121 / CCUG 31486 / LMG 2827 / NBRC 12203 / NCIMB 8253 / ATH 2.4.1.)) Explore Q3IUY6 Go to UniProtKB: Q3IUY6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q3IUY6
Sequence Annotations Expand
Reference Sequence

Small Molecules

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.65 Å
R-Value Free: 0.216 (Depositor), 0.209 (DCC)
R-Value Work: 0.160 (Depositor), 0.168 (DCC)
R-Value Observed: 0.162 (Depositor)

Space Group: P 4₃ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 72.102	α = 90
b = 72.102	β = 90
c = 36.429	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PDB_EXTRACT	data extraction
SBC-Collect	data collection
HKL-3000	data reduction
HKL-3000	data scaling
HKL-3000	phasing
SHELXD	phasing
SHELXE	model building
MLPHARE	phasing
DM	phasing
RESOLVE	phasing
Coot	model building
ARP/wARP	model building

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2010-09-08

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2010-09-08
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2024-11-06
Changes: Data collection, Database references, Derived calculations, Structure summary
